All 100 operating hours or once in year
What?
Replacing the
spark plug
Cleaning the product
Clean the product immediately after each
use. Dried-on grass is extremely hard and dif-
ficult to remove.
– Remove residual grass using a brush or
plastic scraper (do not use any sharp
implements).
– Remove deposits from the wheels.
– Wipe down the product with a slightly
damp cloth.
– Never clean the product with water or
high-pressure jet.
Changing the blades
DANGER! Risk of injury! Never
hold the blade by the cutting edge.
Wear protective gloves when working
with the blade.
► P. 8, item 13
– Lift the machine at the front and set it on
end.
Disassembly
– Loosen the blade screw (35) using a 14
mm hexagon spanner.
– Remove the washer (37).
– Carefully remove the blade (34).
Installation
NOTICE! Risk of product damage!
Ensure the correct installation posi-
tion: the journals (36) must line up
with the holes in the blade.
– Carefully put the blade (34) into place.
– Put the washer (37) into place.
– Tighten the blade screw (35) using a 14
mm hexagon spanner (35-40 Nm).
Replacing the air filter
NOTICE! Risk of product damage!
The product must never be operated
without the air filter, as this can cause
damage to the motor.
How?
► Replacing the spark
plug – p. 51, Replace-
ment spark plugs:
► Technical data –
p. 53.
NOTICE! Risk of product damage!
Always use original air filters
approved by the manufacturer.
► P. 9, item 14
– Switch off the motor and remove the spark
plug connector.
– Open the air filter housing (13).
► P. 9, item 15
– Remove the air filter (38).
– Clean all parts of the air filter unit.
– Fit new air filter.
– Re-close the air filter housing (13).
Checking the motor oil level
► P. 9, item 16
– Unscrew and remove the motor oil filling
plug (10).
– Read-off the oil level on the dip stick on
the underside of the motor oil filling plug.
– The oil level must lie between [A] and [B].
Cleaning/replacing the spark plug
► P. 3, item 2
WARNING! Risk of injury due to
high-voltage! Do not touch the spark
plug connector and spark plug while
the motor is running.
► P. 9, item 17
– Disconnect the spark plug connector (14).
► P. 9, item 18
– Unscrew the spark plug (39) using a spark
plug spanner.
– Check the electrode for discolouration.
Standard colour: light brown
– Check the electrode distance with a feeler
gauge. Correct distance: 0,457-0,61 mm
Cleaning the spark plug
NOTICE! Risk of product damage!
To clean the spark plug, use only wire
brushes with brass bristles. Bristles of
any other material will damage the
electrode!
– Remove rust from the electrode with a
wire brush.
Replacing the spark plug
NOTICE! Risk of product damage!
Fit the spark plug only when motor is
cold.
– Insert a cleaned or new spark plug and
tighten by hand.
