Gude Expert Power Control 8001 Anleitung Seite 62

Spezifikationen
epc8001ResetTime
epc8001Forw EnergyActive
epc8001Forw EnergyReactive
epc8001Forw EnergyActiveResett
able
epc8001Forw EnergyReactiveRes
ettable
epc8001RevEnergyActive
epc8001RevEnergyReactive
epc8001RevEnergyActiveResetta
ble
epc8001RevEnergyReactiveResett
able
epc8001LineSensorName
epc8001spActivePow erChan
epc8001spPow erIndex
epc8001spChanStatus
epc8001spAbsEnergyActive
epc8001spPow erActive
epc8001spCurrent
epc8001spVoltage
epc8001spFrequency
epc8001spPow erFactor
epc8001spPangle
epc8001spPow erApparent
epc8001spPow erReactive
epc8001spAbsEnergyReactive
epc8001spAbsEnergyActiveReset
table
epc8001spAbsEnergyReactiveRe
settable
epc8001spResetTime
epc8001spForw EnergyActive
Expert Power Control 8001
Resettable Absolute Reactive Energy counter.
.100.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.100.1.5.1.2.1.16.x
Forw ard Active Energy counter.
.100.1.5.1.2.1.17.x
Forw ard Reactive Energy counter.
.100.1.5.1.2.1.18.x
Resettable Forw ard Active Energy counter.
.100.1.5.1.2.1.19.x
Resettable Forw ard Reactive Energy counter.
.100.1.5.1.2.1.20.x
Reverse Active Energy counter.
.100.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.100.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.100.1.5.1.2.1.23.x
Resettable Reverse Reactive Energy counter.
.100.1.5.1.2.1.100.x OCTETS
A textual string containing name of a Line Sensor
.100.1.5.5.1.0
Number of Single Port Pow er Channels. Value is zero on EPC 8220
series.
.100.1.5.5.2.1.1.x
Index of Single Port Pow er Channel entries. Indices 0-5 mean Ports A1
to A6, 6-11 are Ports B1 to B6.
.100.1.5.5.2.1.2.x
0 = data not active, 1 = data valid
.100.1.5.5.2.1.3.x
Absolute Active Energy counter.
.100.1.5.5.2.1.4.x
Active Pow er
.100.1.5.5.2.1.5.x
Actual Curent on Pow er Channel.
.100.1.5.5.2.1.6.x
Actual Voltage on Pow er Channel
.100.1.5.5.2.1.7.x
Frequency of Pow er Channel
.100.1.5.5.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.100.1.5.5.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.100.1.5.5.2.1.10.x
L Line Mean Apparent Pow er
.100.1.5.5.2.1.11.x
L Line Mean Reactive Pow er
.100.1.5.5.2.1.12.x
Absolute Reactive Energy counter.
.100.1.5.5.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.100.1.5.5.2.1.14.x
Resettable Absolute Reactive Energy counter.
.100.1.5.5.2.1.15.x
Time in seconds since last Energy Counter reset.
.100.1.5.5.2.1.16.x
Forw ard Active Energy counter.
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
© 2022 GUDE Systems GmbH
62
