Gude Expert Power Control 8001 Anleitung Seite 61

Spezifikationen
Name
epc8001TrapCtrl
epc8001TrapIPIndex
epc8001TrapAddr
epc8001portNumber
epc8001PortIndex
epc8001PortName
epc8001PortState
epc8001PortSw itchCount
epc8001PortStartupMode
epc8001PortStartupDelay
epc8001PortRepow erTime
epc8001PortResetDuration
epc8001Buzzer
epc8001ActivePow erChan
epc8001Pow erIndex
epc8001ChanStatus
epc8001AbsEnergyActive
epc8001Pow erActive
epc8001Current
epc8001Voltage
epc8001Frequency
epc8001Pow erFactor
epc8001Pangle
epc8001Pow erApparent
epc8001Pow erReactive
epc8001AbsEnergyReactive
epc8001AbsEnergyActiveResetta
ble
epc8001AbsEnergyReactiveReset
table
61
Expert Power Control 8001
OID
Description
.100.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.100.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.100.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.100.1.3.1.1.0
The number of Relay Ports
.100.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.100.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.100.1.3.1.2.1.3.x
current state of a Relay Port
.100.1.3.1.2.1.4.x
The total number of sw itch actions ocurred on a Relay Port. Does not
count sw itch commands w hich w ill not sw itch the ralay state, so just
real relay sw itches are displayed here.
.100.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.100.1.3.1.2.1.6.x
Delay in sec for startup action
.100.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.100.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.100.1.3.10.0
turn Buzzer on and off
.100.1.5.1.1.0
Number of suppported Pow er Channels.
.100.1.5.1.2.1.1.x
Index of Pow er Channel entries
.100.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.100.1.5.1.2.1.3.x
Absolute Active Energy counter.
.100.1.5.1.2.1.4.x
Active Pow er
.100.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.100.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.100.1.5.1.2.1.7.x
Frequency of Pow er Channel
.100.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.100.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.100.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.100.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.100.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.100.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.100.1.5.1.2.1.14.x
Type Acc.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
