Spezifikationen
epc8226AbsEnergyActiveResetta
ble
epc8226AbsEnergyReactiveReset
table
epc8226ResetTime
epc8226Forw EnergyActive
epc8226Forw EnergyReactive
epc8226Forw EnergyActiveResett
able
epc8226Forw EnergyReactiveRes
ettable
epc8226RevEnergyActive
epc8226RevEnergyReactive
epc8226RevEnergyActiveResetta
ble
epc8226RevEnergyReactiveResett
able
epc8226LineSensorName
epc8226OVPIndex
epc8226OVPStatus
epc8226spActivePow erChan
epc8226spPow erIndex
epc8226spChanStatus
epc8226spAbsEnergyActive
epc8226spPow erActive
epc8226spCurrent
epc8226spVoltage
epc8226spFrequency
epc8226spPow erFactor
epc8226spPangle
epc8226spPow erApparent
epc8226spPow erReactive
epc8226spAbsEnergyReactive
epc8226spAbsEnergyActiveReset
table
67
Expert Power Control 8221/8226
.58.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.58.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.58.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.58.1.5.1.2.1.16.x
Forw ard Active Energy counter.
.58.1.5.1.2.1.17.x
Forw ard Reactive Energy counter.
.58.1.5.1.2.1.18.x
Resettable Forw ard Active Energy counter.
.58.1.5.1.2.1.19.x
Resettable Forw ard Reactive Energy counter.
.58.1.5.1.2.1.20.x
Reverse Active Energy counter.
.58.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.58.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.58.1.5.1.2.1.23.x
Resettable Reverse Reactive Energy counter.
.58.1.5.1.2.1.100.x
A textual string containing name of a Line Sensor
.58.1.5.2.1.1.x
None
.58.1.5.2.1.2.x
show s the status of the built-in Overvoltage Protection
.58.1.5.5.1.0
Number of Single Port Pow er Channels. Value is zero on EPC 8220
series.
.58.1.5.5.2.1.1.x
Index of Single Port Pow er Channel entries. Indices 0-5 mean Ports A1
to A6, 6-11 are Ports B1 to B6.
.58.1.5.5.2.1.2.x
0 = data not active, 1 = data valid
.58.1.5.5.2.1.3.x
Absolute Active Energy counter.
.58.1.5.5.2.1.4.x
Active Pow er
.58.1.5.5.2.1.5.x
Actual Curent on Pow er Channel.
.58.1.5.5.2.1.6.x
Actual Voltage on Pow er Channel
.58.1.5.5.2.1.7.x
Frequency of Pow er Channel
.58.1.5.5.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.58.1.5.5.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.58.1.5.5.2.1.10.x
L Line Mean Apparent Pow er
.58.1.5.5.2.1.11.x
L Line Mean Reactive Pow er
.58.1.5.5.2.1.12.x
Absolute Reactive Energy counter.
.58.1.5.5.2.1.13.x
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
OCTETS RW
Integer32 RO
INTEGER RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
