Spezifikationen
sen. Die komplette OID würde daher z.B. "1.3.6.1.4.1.28507.58.1.1.1.1" lauten. Man un-
terscheidet in SNMP bei OID's zwischen Tabellen und Skalaren. OID Skalare haben die
Endung ".0" und spezifizieren nur einen Wert. Bei SNMP Tabellen wird das "x" durch
einen Index (1 oder größer) ersetzt, um einen Wert aus der Tabelle zu adressieren.
Name
epc8226TrapCtrl
epc8226TrapIPIndex
epc8226TrapAddr
epc8226portNumber
epc8226PortIndex
epc8226PortName
epc8226PortState
epc8226PortSw itchCount
epc8226PortStartupMode
epc8226PortStartupDelay
epc8226PortRepow erTime
epc8226PortResetDuration
epc8226Buzzer
epc8226ActivePow erChan
epc8226Pow erIndex
epc8226ChanStatus
epc8226AbsEnergyActive
epc8226Pow erActive
epc8226Current
epc8226Voltage
epc8226Frequency
epc8226Pow erFactor
epc8226Pangle
epc8226Pow erApparent
epc8226Pow erReactive
epc8226AbsEnergyReactive
Expert Power Control 8221/8226
OID
Description
.58.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.58.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.58.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.58.1.3.1.1.0
The number of Relay Ports
.58.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.58.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.58.1.3.1.2.1.3.x
current state of a Relay Port
.58.1.3.1.2.1.4.x
The total number of sw itch actions ocurred on a Relay Port. Does not
count sw itch commands w hich w ill not sw itch the ralay state, so just
real relay sw itches are displayed here.
.58.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.58.1.3.1.2.1.6.x
Delay in sec for startup action
.58.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.58.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.58.1.3.10.0
turn Buzzer on and off
.58.1.5.1.1.0
Number of suppported Pow er Channels.
.58.1.5.1.2.1.1.x
Index of Pow er Channel entries
.58.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.58.1.5.1.2.1.3.x
Absolute Active Energy counter.
.58.1.5.1.2.1.4.x
Active Pow er
.58.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.58.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.58.1.5.1.2.1.7.x
Frequency of Pow er Channel
.58.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.58.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.58.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.58.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.58.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
Type Acc.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
