Rowi HIT 2000/2/2 F Premium Originalbetriebsanleitung Seite 31

3. Now take the first and second tube con-
nection and connect this to the middle
tube section by screwing the screws into
the openings. Do not forget to guide the
power cable through.
4. Now place the last tube section on the
tube connection, pull the power cord
through and connect the power cord to
the heating head connection. Firmly fasten
the tube section of the heating head toge-
ther with the remaining sections. Use the
two smaller screws on the upper end of
the tube section for this.
6. Now join the weighted base to the cover.
Use the hexagon nuts and screws supplied
for this.
7. Take the screws and nuts for the castors
and fasten these together with the castors,
from below on the base. Then place the
power cord on the bottom of the base
through the cable guide and fasten with
the cable clip (2 screws).
31/44
