Control Panel - Electrolux SG182N Benutzerinformation

4. CONTROL PANEL

4.1 Display
4
Temperature scale
1
Temperature key
2
ECO mode icon
3
FastFreeze icon
4
4.2 Switching on
1. Plug the appliance into electrical
mains socket.
2. To turn on the appliance, touch the
temperature key. All LED indicators
light up.
The temperature is set to the default
setting (ECO mode). LED indicator next
to ECO mode icon illuminates.
4.3 Switching off
1. To switch off the appliance press the
temperature key for 3 seconds.
All LED indicators turn off.
2. To disconnect the appliance from the
electrical supply, remove the mains
plug from the power socket.
4.4 Temperature regulation
To regulate the temperature, press the
temperature key. Every time the key is
pressed, the set temperature moves by
2
1
3
4
1
2
3
3.5 Door reversibility
Please refer to the separate document
with instructions on installation and door
reversal.
CAUTION!
At every stage of reversing
the door protect the floor
from scratching with a
durable material.
one position and corresponding LED
indicator lights up. Press the temperature
key repeatedly until the required
temperature is selected. The setting will
be fixed.
Selection is progressive,
varying from -15°C to -24°C.
Recommended setting is
-18°C. You can activate it
also by ECO mode.
The set temperature will be reached
within 24 hours. After a power failure the
set temperature remains stored.
4.5 ECO mode
In this mode the temperature is set to
-18°C.
This is the best setting to
ensure good food
preservation with minimal
energy consumption.
To activate ECO mode press the
temperature key repeatedly until LED
indicator next to ECO mode icon lights
up.
4.6 FastFreeze function
This function is used to perform pre-
freezing and fast freezing in sequence in
the freezer compartment. It accelerates
the freezing of fresh food and, at the
same time, protects food products
already stored in the compartment from
undesirable warming.
ENGLISH 63
