Working instructions

► The auto feed attachment must not be
held in the depth stopper area as there
are moving parts!
► Each screw adjustment must be com-
pleted. Interrupted fastening or releasing
of the pressure during adjustment can
result in unsatisfactory machine function.
► The collated screws and the auto feed
attachment can only be replaced when
the power tool is turned off.
► Never use the auto feed attachment in
any other way than specifi ed in this in-
struction manual.
► Use only original screwing bits.
► Use only original collated screws.
► Always store the collated screws in origi-
nal packaging.
► Always work in right angle against the
attached board.
Maintenance of the auto feed attach-
ment
The attachment generally does not require
any maintenance. After long period use, we
recommend to clean with pressurized air.
The auto feed attachment may be lubri-
cated in the area of the carriage guide (see
picture [12 b]).
Prior to cleaning, dismantle the attachment,
as specifi ed above.
Prior to cleaning, remove the collated
screws from the attachment, as specifi ed
in the point Removing the collated screws.
Pull the auto feed attachment from the dry-
wall screwdriver.
Disassembly of the slides
1. Push the depth stopper [9-2] into the
housing until the arresting button [12-1]
is at the level of the sign for dismantling
the slides [12-2] – see fi gure [12 a].
2. Press the arresting button [12-1] and
concurrently remove the slides from the
holder – see fi gure [12 b].
3. Press the orange button [9-1] and con-
currently release the depth stopper – see
fi gure [12 c].
Transport lever disassembly
1. Press the button [13-1] and concurrently
pull it out– see fi gure [13a].
2. Remove the released button [13-1] (fi g-
ure [13 b]) with the transport lever [13-2]
and the spring [13-3] from the slides
(fi gure [13 c]).
Clean individual parts, replace defective or
worn parts, and assemble in the opposite
sequence.
During reassembly of the transport
lever into the slides, pay due care to
correct fi tting of the spring [13-3] in
the transport lever. Incorrect assem-
bly may result in dysfunction of the
belt transport.

Acoustic warning signal

Acoustic warning signals sound and the ma-
chine switches off in the following operating
states:
peep
peep peep
peep peep peep
19
CAUTION
- Battery fl at or machine
overloaded
• Change the battery
pack.
• Place the machine under
reduced stress.
- Machine is overheating
• You must allow the
machine to cool before
using again.
- LiIon battery pack is
faulty or has overheated.
• Once the battery pack
has cooled, perform a
functional check using
the charger.
