Original Instruction / Spare Parts List - Protool DuraDrive DWC 18-2500 DEC Originalbetriebsanleitung

Technical data – DuraDrive
Cordless drywall screwdriver
– Original instruction
Motor voltage
Idle speed*
Torque (hard / soft)
Chuck
Weight (without battery pack)
Weight with depth stopper
(without battery pack) 1.2 kg
Weight with auto feed attachment
(without battery pack)
Accessories
Charger
Mains voltage (input)
Mains frequency
Charging voltage (output)
Rapid charging
Conservation charging current, pulsating
Charging times for:
LiIon 3,0 Ah
LiIon 1,5 Ah
Permitted charging temperature range
Temperature monitoring
Battery packs
Voltage
Capacity
Weight
* Speed specifi cations with fully charged battery pack.
1 Symbols
Warning of general danger
Risk of electric shock
Wear ear protection!
Wear a dust mask!
Wear eye protection!
Read the instructions
Do not dispose of power tools
into household waste!
Advice or tip
►
80% approx. 50 min.
100% approx. 65 min.
80% approx. 25 min.
100% approx. 35 min.
DWC 18-2500
DEC
18 V
0 – 2500/min
7 / 18 Nm
¼" DIN 3126 / ISO 1173
1.1 kg
1.2 kg
1.5 kg
BC 3
230 – 240 V ~
50 / 60 Hz
7.2 – 18 V =
max. 3 A
approx. 0.06 A
–5 °C to +45 °C
via NTC resistor
BP 18 3,0 Ah LiIon
18 V
3.0 Ah
0.715 kg
2 Power tool features
[1-1] Bit storage
[1-2] Switch
[1-3] Forward / reverse switch
[1-4] AUTO/MAN switch
[1-5] Depth stopper
[1-6] Bit
[2-1] Battery pack
[2-2] Buttons for releasing the battery
[3-1] Charger
[3-2] LED
[4-1] Depth stopper
[4-2] Bit holder
[4-3] Bit
[4-4] Chuck
[4-5] Gear box
14
GB
DWC 18-4500
DEC
18 V
0 – 4500/min
5 / 14 Nm
1.1 kg
1.5 kg
BP 18 1,5 Ah LiIon
18 V
1,5 Ah
0.4 kg
