7.3 Hook and clip

Use the clip [5-1] to temporarily attach the
screwdriver on the working clothing – it can
be attached by means of a screw [5-2] to
the left or right of the power tool, and it is
suitable for right and left handed people –
see fi gure [5].
The screwdriver is equipped with a hook
[6-1], which is used for occasional machine
suspension. It can be attached to the left
or right of the power tool, by means of a
screw [6-2] – see fi gure [6].

7.4 Auto feed attachment

The auto feed attachment enables to work
continuously, without unnecessary delays.
Fitting the auto feed attachment
At fi rst remove the depth stopper [3-1], bit
holder [3-2] and bit, as specifi ed in point 6.
Set the switch [1-4] into MAN position.
Push the long bit [7-1] completely to the
hexagonal spindle opening [3-4].
Then fi t the auto feed attachment on the
gear box. Push the attachment until it en-
gages in the groove of the gear box.
The attachment can be mounted at 30°
steps.
Removing the auto feed attachment
Use power to carefully pull the attachment
from the gear box.
Setting the screw length
Press button [8-1] to remove and insert the
depth stopper [8-2] and set the required
screw length. Read the set screw length on
the stopper sides [8-3].
Inserting collated screw strips
Pull the collated screws [9-3] through the
bottom guiding of the attachment, then
push the strip through the second guid-
ing until it engages in the working position.
Pull the belt slightly to make sure that it is
safely fi tted. Make sure that the fi rst screw
is in the screwing axes – see fi gure [9].
Use the wheel [9-1] to set the required
screwing depth. Turn to the right for in-
serting the screws deeper, and to the left
to screw to lower depth. The actual setting
position is visible on the presetting indica-
tor [9-2].
Upon setting, set some screws for testing
and use the wheel [9-1] to adjust the depth,
if required. Each setting change complies
with the stopper shift o ± 0.1 mm.
► We recommend to screw in automatic
mode – see point 7.1 b).
Removing the collated screws
Pull upwards to remove the belt (fi gure
[10] ) or press the transport lever and
concurrently pull the belt downwards (fi g-
ure [10] ).
8

Working instructions

► The auto feed attachment must not be
held in the depth stopper area as there
are moving parts!
► Each screw adjustment must be complet-
ed. Interrupted fastening or releasing of
the pressure during adjustment can re-
sult in unsatisfactory machine function.
► The collated screws and the auto feed
attachment can only be replaced when
the power tool is turned off.
► Never use the auto feed attachment in
any other way than specifi ed in this in-
struction manual.
► Use only original screwing bits.
► Use only original collated screws.
► Always store the collated screws in origi-
nal packaging.
► Always work in right angle against the
attached board.
Maintenance of the auto feed attach-
ment
The attachment generally does not require
any maintenance. After long period use, we
recommend to clean with pressurized air.
The auto feed attachment may be lubri-
cated in the area of the carriage guide (see
picture [11 b]).
Prior to cleaning, dismantle the attachment,
as specifi ed above.
Prior to cleaning, remove the collated screws
from the attachment, as specifi ed in the
point Removing the collated screws.
Pull the auto feed attachment from the dry-
wall screwdriver.
