5.3 Wall mounting

There are two elongated holes on the back
of the BC 3 for mounting the charger to
a wall using two screws (e.g. round head
or fl at head screw with shank diameter of
5 mm).
Insert the two screws into the wall at a dis-
tance of 96 mm from one another and leave
the screw heads protruding approx. 4 mm.
6 Power tool settings
► Setting must be done only when the pow-
er tool is turned off and will be accepted
only after restarting it.
6.1 Changing the direction
of rotation
The forward / reverse switch [1-3] changes
the direction of rotation.
Move switch from right to left = clockwise
rotation;
Move switch from left to right = anticlock-
wise rotation.
7 Tool holder,
attachments
Bit holder
The bit holder is used for fast replacement
of bits.
CAUTION
Risk of cutting injuries when chang-
ing the tool!
► Wear protective gloves!
Bit holder assembly
Set the switch [1-4] into MAN position. Set
the bit holder [4-2] completely to the hex-
agonal spindle opening [4-4].
Attach bit into the holder [4-3].
Then attach the depth stopper on the gear
box as specifi ed in point 8.2.
Bit holder disassembly
Remove the depth stopper as specifi ed in
point 8.2. Use power to pull out the holder
from the spindle opening.
Bit replacement
You can use the depth stopper [1-5] for
the bit replacement [1-6]. Attach the depth
stopper on the bit (see fi gure [4 b]). By
means of jamming the depth stopper with
the bit and concurrent pulling, it is possible
to pull out the bit. Then attach a new bit
in the holder.
8 Operation

8.1 Switching on and off

The machine can be switched on by means
of several methods:
a) Set the forward / reverse switch [1-3]
into machine clockwise operation.
Set the switch [1-4] into MAN position. In
order to switch on the power tool, apply the
switch [1-2] and concurrently press the bit
on the screw.
Use the switch [1-2] to gradually regulate
the speed.
Pressing only the switch [1-2] does
not start the machine – it is not a ma-
chine fault!
Upon screwing to the required depth,
the power tool switches off!
b) Set the forward / reverse switch [1-3]
into machine clockwise operation.
Set the switch [1-4] into AUTO position.
Press the bit on the screw and the power
tool will switch on. Switch [1-2] does not
need to be pressed. Maximum speed is set
automatically.
Pressing only the switch [1-2] does
not start the power tool – it is not a
machine fault!
Upon screwing to the required depth,
the power tool switches off!
c) Set the forward / reverse switch [1-3]
