Installation, fitting, connection and initial commissioning
5. Remove the protective films from the
side end profiles (b).
6. Affix the end profiles to the left and right
edges of the dishwasher. This will pre-
vent a crack being visible between the
dishwasher and the adjacent kitchen
cupboards.
7. Push the dishwasher into the recess.
(26)
8. To enable the dishwasher to be posi-
– The front feet are equipped with slots.
(b)
– With the help of the middle adjustment
9. Check the alignment with a spirit level.
10. Make sure that the top edge of the dish-
11. Screw the dishwasher to the kitchen unit.
tioned in a level position, both the front
(26) and back appliance feet can be ad-
justed by up to 50 mm.
Insert a screwdriver into one of the slots
and use it to turn the appliance feet to
the desired height.
screw you can adjust the height of the
rear appliance foot. Use a Phillips-tip
screwdriver for this.
washer is up to the bottom edge of the
worktop to prevent it from tipping forward
when you open the dishwasher door.
– If you have granite worktops,
remove the internal side cover caps
(f) and screw the dishwasher to
the adjacent kitchen cupboards.
Re-cover the screws (i) with the cover
caps.
– For all other worktops, screw the
mounting bracket (e) firmly to the work
surface.
Page EN-31
(e)
(j)
(f) (i)
