MAIN COMPONENTS

A) ..................................................................................................................................................................................................Nozzle
B) .............................................................................................................................................................................Balancer connection
C) ......................................................................................................................................................................................Nails conveyor
D) .........................................................................................................................................................................Tensile strenght button
E) .........................................................................................................................................................................................Oil tank plug
F) .................................................................................................................................................................. Compressed air connection
G) .............................................................................................................................................................................Head carring nozzle
H) .................................................................................................................................................................................Protection bottom

PARTIES PRINCIPALES

A) .....................................................................................................................................................................................................Buse
B) ...................................................................................................................................................................................Etrier de support
C) .....................................................................................................................................................................Bol de récupération clous
D) ................................................................................................................................................................................Bouton de traction
E) ..............................................................................................................................................................Orifice de remplissage d'huile
F) ........................................................................................................................................................................Raccord d'air comprimè
G) ....................................................................................................................................................................................Tête porte buse
H) ...............................................................................................................................................................................Culot de protection
HAUPTSÄCHLICHE TEILE
A) ............................................................................................................................................................................................Mundstück
B) ................................................................................................................................................................................Balancerhalterung
C) .......................................................................................................................................................................................Nagelbehälter
D) ..............................................................................................................................................................................Auslöser für Ziehen
E) ................................................................................................................................................................................. Öleinfüllschraube
F) ................................................................................................................................................................................. Druckluftanschluß
G) .................................................................................................................................................................................. Mundstückträger
H) ............................................................................................................................................................................................Schutzring

PARTES PRINCIPALES

A) ................................................................................................................................................................................................ Inyector
B) ...............................................................................................................................................................................Toma balanceador
C) ..............................................................................................................................................................................Encanalador clavos
D) ............................................................................................................................................................................ Pulsador de tracción
E) ............................................................................................................................................................................ Tapón tanque aceite
F) .................................................................................................................................................................... Conexión aire comprimido
G) ............................................................................................................................................................... Tubito externo porta inyector
H) ..........................................................................................................................................................................Fondillo de protección
