4 OPERATION

4.4.3 Temperature adjustment

The temperature value measured by the Pt1000 can be corrected. Enter the required offset
of temperature (within the limit ± 5°C), then validate.
The temperature unit is as selected in previous parameter menu. The selected temperature
value influences the computed pH value.
T ° ADJUST ENTER
SIMUL
ENTER
The temperature adjustment remains active until another value is entered.
The temperature adjustment is not valid within the manual temperature compensation mode
(refer to § 4.3.5).
4.4.4 pH Simulation
A pH (or T°) value can be simulated in this menu, to test the entire system without liquid.
The simulated value influences the current and relays outputs.
The simulation mode also allows the sensor to be removed without interruption of the pro-
cess.
SIMUL ENTER
1)
SIMUL
1)
SIMUL
Quit the sub-menu SIMUL by pressing
1)
The simulation remains active until the user enters another sub-menu.
+ 0.0 °C
Enter the temperature
offset value (°C or °F)
0......9
+ 1.2 °C
PH SIMUL
Enter the pH value
T ° SIMUL
0......9
Enter the temperature value
or
0......9
E-33-
PH TRANSMITTER 8205
ENTER
PH=00.00
ENTER
PH=10.50
ENTER 00.0 °C
ENTER
021 °C
.
0......9
0......9
