2.2 Basic Specifications
Model
Item
Print method
Print width
Dot density
Print speed
Number of print
1
columns*
Character size
Character type
Logo registration/print Capable of registering user-defined characters and logos into flash memory.
NV bit map data area
Types of bar code
Line spacing
Paper
Interfacing
Input buffer
Supply voltage
Power consumption
AC adapter spec.
Type
Weight
Outside dimensions
Operating temperature 5 to 40°C; 35 to 85% RH (No condensation)
and humidity
Storage temperature
and humidity
Reliability
2
Safety Standard*
1
*
The number of print columns can be selected with the DIP switch.
2
*
Represents the safety standards acquired when CITIZEN SYSTEMS-made
adapters (31AD series) are used.
iDP3240-RF120
iDP3240-PF120
Line thermal dot print method
104 mm/832 dots
8 dots/mm (203 dpi)
80 mm/sec (Fastest, printing ASCII, print density level 2, applicable to
printing of 60 or fewer columns)
Font A: 69/60 columns (12 × 24)
Font B: 92/80 columns (9 × 24)
Font A: 1.25 × 3.00 mm; Font B: 0.88 × 3.00 mm
Alphanumeric characters, International characters, Codepages PC437,
Katakana, PC850, PC860, PC863, PC865, PC852, PC866, PC857, and Windows
codepage
256K bytes
UPC-A/E, JAN (EAN) 13/8 columns, ITF
CODE 39, CODE 128, CODABAR, CODE 93
4.23 mm (1/6 inches); selectable using commands.
Thermal paper roll: 112 mm +0/–1 × φ 83 mm (See "2.3 Print Paper
Specifications".)
Serial (RS-232C), Parallel (IEEE1284 compliant, Bi-directional communication)
64K bytes (4K bytes selectable with a DIP switch)
DC 24 V ±7%
Approx. 100 W
Rated input: AC 120 to 240 V, 50/60 Hz, 120 VA
Rated output: DC 24 V, 1.9 A
31AD-U
Main body: Approx. 1.3 kg; AC adapter: Approx. 0.45 kg
186 (W) × 201 (D) × 123 (H) mm
–20 to 60°C; 10 to 90% RH (No condensation)
Print head life: Pulse resistance 1 × 10
Wear resistance 100 Km (At normal temperature/humidity
with recommended paper used)
Auto cutter life: 500,000 times of cutting (At normal temperature/humidity
with recommended paper used)
UL, C-UL, FCC Class A
8
pulses (Print ratio 12.5%)
— 5 —
iDP3240-RF230
iDP3240-PF230
31AD-E
TUV, GS, CE marking
