Citizen iDP3410 Bedienungsanleitung

Citizen iDP3410 Bedienungsanleitung

Dot matrix printer
Vorschau ausblenden
Inhaltsverzeichnis

Werbung

Quicklinks

Diese Anleitung herunterladen
DOT MATRIX PRINTER
iDP3410
MODEL

Werbung

Inhaltsverzeichnis
loading

Verwandte Anleitungen für Citizen iDP3410

Inhaltszusammenfassung für Citizen iDP3410

  • Seite 1 DOT MATRIX PRINTER iDP3410 MODEL...

  • Seite 2: Declaration Of Conformity

    User's Manual Declaration of Conformity Manufacturer's Name : Japan CBM Corporation Manufacturer's Address : CBM Bldg.,5-68-10, Nakano, Nakano-ku, Tokyo 164-0001, Japan Declare the Product Product Name : Dot Matrix Printer Model Number (s) : iDP3410 (iDP3410R/P, iDP3410S/C, iDP3410T/I) (S.NO.98X0001 - )

  • Seite 3: Important Safety Instructions

    User's Manual IMPORTANT SAFETY INSTRUCTIONS • Read all of these instructions and save them for future reference. • Follow all warnings and instructions marked on the product. • Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

  • Seite 4: Wichtige Sicherheitsanweisungen

    User's Manual WICHTIGE SICHERHEITSANWEISUNGEN • Lesen Sie die nachfolgenden Anweisungen sorgfältig durch und bewahren Sie sie auf. • Befolgen Sie alle auf dem Drucker vermerkten Hinweise und Anweisungen. Vor dem Reinigen grundsätzlich Stecker aus der Steckdose ziehen. Keine Flüssigkeiten oder Aerosolreiniger benutzen.
  • Seite 5 User's Manual IMPORTANT: This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 off FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
  • Seite 6 User's Manual <CAUTIONS> Prior to using the equipment, be sure to read this User's Manual thoroughly. Please keep it handy for reference whenever it may be needed. The information contained herein may be changed without prior notice. Reproduction of part or all of this User's Manual without permission is strictly prohibited.
  • Seite 7 User's Manual SAFETY PRECAUTIONS ----- BE SURE TO OBSERVE In order to prevent hazards to an operator or other persons and damage to property, be sure to observe the following precautions.  The following describes the degrees of hazard and damages that can occur if the given instructions are neglected or the equipment is incorrectly operated.
  • Seite 8 User's Manual WARNING !  Never handle the equipment in the following manners, as it may break, become out of order, or overheat causing smoke and resulting in fire or electric shock. If the equipment is used in an abnormal condition, such as when broken, then problems, smoke emission, abnormal odor/noise, and fire can result.

  • Seite 9: Precautions For Installation

    User's Manual PRECAUTIONS FOR INSTALLATION • Do not use or store the equipment in a place exposed to fire, moisture, or direct sunlight, or in a place near a heater or a thermal device where the prescribed operating temperature and humidity are not met, or in a place exposed to much oil, iron powder, or dust.
  • Seite 10 User's Manual PRECAUTIONS FOR HANDLING Do not handle the equipment in the following manners, because problems may result. • Do not use a power supply other than the specified AC adapter. • Do not print when there is no recording paper or ink ribbon set in the equipment. The print head may be damaged •...

  • Seite 11: Daily Maintenance

    User's Manual DAILY MAINTENANCE • Prior to starting maintenance work, be sure to turn off the main body. • Use a dry soft cloth to wipe off stains and dust from the surfaces of the main body case. For severe soiling, dip the cloth in water and wring it, for wiping off the soil.

  • Seite 12: Inhaltsverzeichnis

    User's Manual CONTENTS 1. OUTLINE ............................... 1 1.1 Features ................................1 1.2 Unpacking ..............................1 2. BASIC SPECIFICATIONS........................2 2.1 Model Classification............................2 2.2 Basic Specifications............................3 2.3 Paper Specification............................4 2.3.1 Recommended Paper..........................4 2.3.2 Printing Position ............................4 2.3.2 Cutter Layout............................
  • Seite 13 User's Manual 11. DRAWER KICK-OUT CONNECTOR AND POWER CONNECTOR ..........31 11.1 Specifications of Drawer Kick-Out Connector................... 31 11.2 Connector's Pin Configuration ........................31 11.3 Drive Circuit............................... 31 11.4 Specifications of Power Supply Connector ....................32 12. MAINTENANCE AND SERVICE ...................... 33 13.
  • Seite 14 12. WARTUNG UND DIENST ....................... 141 Note: CITIZEN, CITIZEN logo are registered trademark of CITIZEN WATCH CO., LTD. ESC/POS and EPSON are a trademark and registered trademark of SEIKO EPSON Corporation. STAR is a registered trademark of Star Micronics Corporation.

  • Seite 15: Outline

    User's Manual 1. OUTLINE This is a small-size dot impact printer developed for various data communication terminals, POS terminals, kitchen-use printers, bank card, terminals, and so on. Its abundant built-in features allow you to widely use this printer for different applications. Prior to using it, read and understand this manual thoroughly.

  • Seite 16: Basic Specifications

    User's Manual 2. BASIC SPECIFICATIONS 2.1 Model Classification The printer model is classified by the following designation method. iDP3410 Model Name AC adapter 120: For 120 V AC 230: For 230 V AC Character Set F: International Interface CBM Mode...

  • Seite 17: Basic Specifications

    User's Manual 2.2 Basic Specifications Model iDP3410-*F120 iDP3410-*F230 Item Printer mechanism DP-410 Series (CITIZEN) Print method Serial dot impact method (Bi-directional print) Print width 64 mm Print head 9 pins Print speed Approx. 3 lines/sec. (At single-color continuous print)

  • Seite 18: Paper Specification

    User's Manual 2.3 Paper Specification 2.3.1 Recommended Paper • Type Normal paper and non-carbon paper • Paper width 76 +/- 0.5 mm • Paper thickness : Single-sheet paper --- 45∼55 kg / 1,000 sheets / 1,091 x 788 mm;...

  • Seite 19: Outer Appearance And Component Parts

    User's Manual 3. OUTER APPEARANCE AND COMPONENT PARTS CITIZEN...

  • Seite 20: Operation

    User's Manual 4. OPERATION 4.1 Connecting AC Adapter (1) Turn off the Power switch. (2) Connect the cable connector of the AC adapter to the power connector located on the back of the printer. (3) In order to prevent disconnection of the cable connector, put it through a wire saddle, as shown in the figure below.

  • Seite 21: Connecting Interface Cable

    User's Manual 4.2 Connecting Interface Cable (1) Turn off the power. (Mating side included) (2) Check the top and bottom of the cable terminals, and connect to the interface connector. (3) Fix the cable terminals. • Serial Interface: Tighten screws, to fix.

  • Seite 22: Setting The Cassette Ribbon

    User's Manual 4.4 Setting the Cassette Ribbon (1) Open the printer cover. (2) If the ribbon is slackened, turn the knob in the arrow-indicated direction to give the tension to it before setting. (3) While putting the ribbon in between the head cover and platen, push the locking claws into the holder of the printer.

  • Seite 23: Inserting The Paper

    User's Manual 4.5 Inserting the Paper (1) Put your hands in the concave parts on both sides of the printer cover, and open it until it comes to a stop. (2) Cut the end of the paper roll at close to a right angle.
  • Seite 24 User's Manual : • If the paper is slack, rewind it, to remove the slack. CAUTION • If the paper is set slantwise, operate the paper-free lever, to correct the paper position. • While printing, do not hold the paper. This can cause a paper jam.

  • Seite 25: How To Remove Remaining Paper Roll

    User's Manual 4.6 How to Remove Remaining Paper Roll (1) Open the printer cover. (2) Pushing the paper-free lever in the arrow direction, pull out the paper roll. CAUTION When pulling out the paper (Forward/Reverse direction), be sure to operate the paper- free lever.

  • Seite 26: Operation Panel And Display Of Error

    User's Manual 4.8 Operation Panel and Display of Error (1) POWER lamp(Green) Illuminated when the power is turned on. (2) ERROR lamp(Red) Illuminated when the printer is out of paper or has a printer mechanical error or communication error.

  • Seite 27: Operation Flow At Power-On

    User's Manual 4.9 Operation Flow at Power-on Power-on Feed SW ? "Clear Data in Buffer" Buffer data Yes(FEED SW) and Enlarged Red Print 1 Sec. Passed 1 Sec. Passed FEED SW ? FEED SW ? (CONTINUE) (AGAIN) Test Print Input Buffer Clear Prints"...

  • Seite 28: Dip Switch Setting

    User's Manual 5. DIP SWITCH SETTING 5.1 Location of DIP Switch (1) Turn off the power. (2) Remove a cassette ribbon. The DIP switches are located as shown in the figure below. (Only DS1 provided for the parallel interface)

  • Seite 29: Dip Switches Setting

    User's Manual 5.2 DIP Switches Setting 1) DIP Switch 1 Function Upon Shipment from Factory DS1-1 Auto cutter DS1-2 International characters ON *2 ″ DS1-3 See the Table below ON *2 ″ DS1-4 ON *2 DS1-5 Paper used DS1-6...
  • Seite 30 User's Manual 2) DIP Switch 2 Function Factory Setting DS2-1 Bit length 8 bits 7 bits DS2-2 Parity DS2-3 Odd/Even Even DS2-4 Communication mode DTR/DSR XON/XOFF DS2-5 Baud rate ″ DS2-6 See the table below ″ DS2-7 − −...

  • Seite 31: Preset Jumper Setting

    User's Manual 6. PRESET JUMPER SETTING 6.1 Location of Preset Jumper (1) Turn off the power. (2) Remove a cassette ribbon. (3) Remove the top cover. The preset jumper is located as shown in the figure below. Serial Interface Parallel Interface 6.2 Preset Jumper Table...

  • Seite 32: Mode Setting Method

    User's Manual 7. MODE SETTING METHOD This printer has the CBM, STAR, and ESC/POS mode. Any desired mode can be selected and set according to your need. (1) Setting method • See 5. DIP SWITCH SETTING. • Seeing the settings of the DIP switch 1-9 and 1-10 and those of the preset jumper, set each mode.

  • Seite 33: Input Buffer Backup Function

    User's Manual 8. INPUT BUFFER BACKUP FUNCTION 8.1 Buffer Size With the DIP switch, you can set either 6K bytes or 256 bytes. → 6K bytes DIP switch 1-8 OFF → 256 bytes 8.2 Input Buffer Backup Even if the power is turned off or fails during the printing process, the data in the input buffer will be saved.

  • Seite 34: Parallel Interface

    User's Manual 9. PARALLEL INTERFACE 9.1 Specifications • Data input system : 8-bit parallel system (DATA1 to DATA8) • Control signals : ACK, BUSY, STB, FAULT, SELECT, RESET, COMPULSION • Applicable connectors : Printer side --- 57LE-40360 (Equivalent to anphenol),...

  • Seite 35: Input And Output Signals

    User's Manual 9.3 Input and Output Signals 9.3.1 Input and Output Signals (1) Input signals to the printer • DATA : An 8-bit parallel signal. (Positive logic) • STB : A strobe signal to read the 8-bit data. (Negative logic) •...

  • Seite 36: Electrical Characteristics

    User's Manual 9.3.2 Electrical Characteristics (1) Input signal level All the input signals are at the TTL level. "HIGH" level : 2.0 V at minimum "LOW" level : 0.8 V at maximum (2) Output signal level All the output signals are at the TTL level.

  • Seite 37: Timing Chart

    User's Manual 9.3.3 Timing Chart (1) Data input and printing timing T1, T2, T3 : 0.5 µs MIN : 270 ns MAX : 2.3 µs TYP : 500 ms MIN (At power-on) 9.3.4 Data Receiving Control When the BUSY signal is at "LOW," the printer can receive the data from the host, but when at "HIGH,"...

  • Seite 38: Serial Interface

    User's Manual 10. SERIAL INTERFACE 10.1 Specifications (1) Synchronous system: Asynchronous (2) Baud rate: 150, 300, 600, 1,200, 2,400, 4,800, 9,600, or 19,200 bps (User selectable) (3) Configuration of one word • Start bit : 1 bit • Data bits : 7 or 8 bits (User selectable) •...

  • Seite 39: Connector's Pin Configuration

    User's Manual 10.2 Connector's Pin Configuration Mode STAR ECS/POS ← ← ← ← ← ← ← ← ← PE (HI-LEVEL) FAULT FAULT mTXD mRXD ← ← RESET Cautions: 1. An RS-232C signal is based on the EIA RS-232C. 2. When the data is not being transferred, the received data should be always maintained as a mark.

  • Seite 40: Input And Output Signals

    User's Manual 10.3 Input and Output Signals 10.3.1 Input and Output Signals (1) RXD This is a serial received data signal. When a framing error, overrun error, or parity error occurs, that data is printed as "?". (2) DTR When this signal is Ready, write the data or a command.
  • Seite 41 User's Manual (8) RCH When the printer is ready to receive, this signal is turned to Space. This signal line is the same as DTR. (9) mTXD TXD signal for the diode gate. (10) mRXD RXD signal for the diode gate.

  • Seite 42: Data Configuration

    User's Manual 10.3.2 Data Configuration Mark , ..Space (1) Start Bit (2) Data Bit (+ Parity Bit) (3) Stop Bit (1 or More) (1) Start bit After a lapse of 1/2 bit from a mark-to-space fall edge, the state is read again, and if it is a space, it is recognized as the start bit.

  • Seite 43: Error Detection

    User's Manual 10.3.3 Error Detection A parity error, framing error, and overrun error are detected. When an error is detected, that data is stored in the buffer as "?". (1) Framing error This error results when a space is detected in detecting the stop bit. That data is stored in the buffer as "?".

  • Seite 44: Electrical Characteristics

    User's Manual 10.3.6 Electrical Characteristics (1) RS-232C circuit Input (RXD, DSR, mRXD) [Printer Side] [Host Side] Mark=(-8V): Stop bit Space=(+8V): Start bit Equivalent MAX232 Output (DTR, TXD, mTXD, RCH, RTS, FAULT) Equivalent to MAX232 Mark=(-8V): At Busy Mark=(-8V): 1...

  • Seite 45: Drawer Kick-Out Connector And Power Connector

    User's Manual 11. DRAWER KICK-OUT CONNECTOR AND POWER CONNECTOR 11.1 Specifications of Drawer Kick-Out Connector (1) Drawer kick-out drive signal Parallel Interface ----- Can be learned at the no. 34 pin of the interface connector Serial Interface ----- Provided with a command to learn the status in the Star and ESC/POS modes.

  • Seite 46: Specifications Of Power Supply Connector

    User's Manual 11.4 Specifications of Power Supply Connector This is a power connector from an exclusive AC adapter. Connector’s Pin Configuration Function +24V Jack used : HEC0470-01-640(HOSHIDEN) or equivalent Applicable plug : JXP series Type-A (I.D. 2.45 mm, O.D. 5.5 mm) (HOSHIDEN) or equivalent •...

  • Seite 47: Maintenance And Service

    User's Manual 12. MAINTENANCE AND SERVICE For the information on maintenance and service, please contact our dealer or at the following address. Northern America Other Areas CBM America Corporation Japan CBM Corporation Service Center Information Systems Division 363 Van Ness Way CBM Bldg., 5-68-10, Nakano...

  • Seite 48: Print Control Functions

    User's Manual 13. PRINT CONTROL FUNCTIONS 13.1 CBM Mode 13.1.1 Command List Command Function Code Page FF n n-line paper feed 0CH n Specifying the double width character Canceling the double width character Printing and paper feed Printing DC 1...

  • Seite 49: Description Of Items

    User's Manual 13.1.2 Description of Items XXXX [Function] Command name [Code] A row of command constituent code is represented by a hexadecimal number with < >H, binary number with < >B, and a decimal number with < >. [ ]k means a repeat count of k- times.
  • Seite 50 User's Manual Details FF n [Function] n-line paper feed [Code] <0C>H n 1 ≤ n ≤ 127 [Range] [Outline] This command feeds the paper by n-lines. You can set n = 1 to 127 lines. If the print buffer contains the data, use of this command feeds the paper by n-lines after printing the data.
  • Seite 51 User's Manual [Function] Canceling the double width character [Code] <0F>H [Outline] This command cancels the double width characters set with SO. The data following this command are printed in the ordinary character width. [Function] Printing and paper feed [Code] <0A>H...
  • Seite 52 User's Manual [Function] Specifying the red print [Code] <13>H [Outline] This command specifies red-color characters. All the characters in one line are printed in red by prefixing the print data with this command and sending it to the printer. When you want to use red characters, use this command for each line.
  • Seite 53 User's Manual ESC "*" n1 n2 [Function] Specifying the bit image mode [Code] <1B>H <2A>H n1 n2 1 ≤ n1 + 256 × n2 ≤ 378 [Range] [Outline] This command allows printing in the bit image mode. Divide the number of dots printed by 256 and assume its quotient to be n2 and remainder to be n1.
  • Seite 54 User's Manual ESC "2" [Function] Setting the 2/9-inch line feed width [Code] <1B>H <32>H [Outline] This command sets the line feed width to 2/9 inch. ESC "3" [Function] Setting the 1/6-inch line feed width [Code] <1B>H <33>H [Outline] This command sets the line feed width to 1/6 inch(Default).
  • Seite 55 User's Manual ESC "N" n [Function] Specifying the perforation skip [Code] <1B>H <4E>H n 1 ≤ n ≤ 126 [Range] [Outline] This command feeds(Skips) the lines specified with n without printing. However, you cannot specify beyond the length of one page.
  • Seite 56 User's Manual ESC "t" n [Function] Selecting the character code table [Code] <1B>H <74>H n 0 ≤ n ≤ 255 [Range] [Outline] This command selects Page-n of Character Code Table. [Default] Depends upon DIP switch setting. Character Code Table...
  • Seite 57 User's Manual ESC BEL n1 n2 [Function] Setting the external device drive pulse width [Code] <1B>H <07>H n1 n2 1 ≤ n1 ≤ 127 1 ≤ n2 ≤ 127 [Range] [Outline] This command sets the power-on time to drive an external device (Cash drawer).
  • Seite 58 User's Manual [Function] Driving command B drawer-1 [Code] <1C>H [Outline] This command drives the drawer connector No. 2 pin under the condition set with the <ESC><BEL> n1 n2 command. [Function] Driving command for drawer-2 [Code] <1A>H [Outline] As soon as this command is received, the drawer connector no. 5 pin is driven. The power-on time is 200 ms ON and 200 ms OFF stationary.
  • Seite 59 User's Manual ESC "R" n [Function] Selecting the international character set [Code] <1B>H <52>H n 0 ≤ n ≤ 10 [Range] [Outline] This command selects the international characters according to the value of n. Character Set Character Set U.S.A.
  • Seite 60 User's Manual ESC "&" <0> n1 n2 [m0 m1 ... m5 m6 m7 m8 m9] n2 - n1 + 1 [Function] Defining the Download character set [Code] <1B>H <26>H <00>H n1 n2 [m0 m1 ... m5 m6 m7 m8 m9] n2 - n1 + 1 32 ≤...
  • Seite 61 User's Manual ESC "%" n [Function] Specifying/Canceling the download character set [Code] <IB>H <25>H n [Outline] This command selects/deselects the download character set. The download characters cannot be printed by simply defining them with the above-mentioned ESC & 0 command.
  • Seite 62 User's Manual ESC DC3 n [Function] Printing the message [Code] <1B>H <13>H n 1 ≤ n ≤ 10 [Range] [Function] This command prints a message. If the value of n is specified beyond the range, the message will not be printed.
  • Seite 63 User's Manual ESC DC2 n1 n2 [Function] Deleting the download character, message, bit image [Code] <1B>H <12>H n1 n2 0 ≤ n1 ≤ 3 [Range] 0 ≤ n2 (Specify 0 at n1 = 0) (1 ≤ n2 ≤ 10 at n1 = 1) (32 ≤...
  • Seite 64 User's Manual GS "*" n1 n2 [d] n1 × n2 × 8 [Function] Defining the download, bit image <1D>H <2A>H <n1> <n2> [<d>] n1 × n2 × 8 [Code] 1 ≤ n1 ≤ 45 0 ≤ n2 ≤ 24 [Range] Note) Take care that the number of data (n1×n2×8) is equal to or smaller than 2,048.
  • Seite 65 User's Manual GS / m [Function] Printing the download, bit image [Code] <1D>H <2F>H m 0 ≤ m ≤ 255 [Range] [Outline] This command prints the bit image saved in the number specified with m. [Caution] If the print buffer contains the data, this command will be ignored. If the bit image has not been saved in the specified number, this command will be ignored.

  • Seite 66: Star Mode

    User's Manual 13.2 STAR Mode 13.2.1 Command List Command Function Code Page ESC R n Selecting the international character set 1BH 52H n ESC 6 1BH 36H ESC 7 1BH 37H ESC M 1BH 4DH ESC P 1BH 50H...
  • Seite 67 User's Manual Command Function Code Page ESC BEL n1 n2 Setting the external device drive pulse width 1BH 07H n1 n2 Driving command A for drawer-1 Driving command B for drawer-1 Driving command for drawer-2 Buzzer-on Canceling the print data...
  • Seite 68 User's Manual Details ESC “R” n [Function] Selecting the international character set [Code] <1B>H <52>H n 0 ≤ n ≤ 10 [Range] [Outline] This command selects the international characters according to the value of n. Character Set Character Set U.S.A.
  • Seite 69 User's Manual [Function] Canceling the double width character [Code] <14>H [Outline] This command deselects the double width characters set with SO. The data following this command will be printed in ordinary characters. ESC "E" [Function] Specifying the highlight character [Code] <1B>H <45>H...
  • Seite 70 User's Manual ESC "-" n [Function] Specifying/Canceling the underline [Code] <1B>H <2D>H n [Outline] This command selects/deselects an underline. The underline is selected at n = 1 and deselected at n = 0. The space by the horizontal tab is not underlined.
  • Seite 71 User's Manual [Function] Specifying the inverted character [Code] <0F>H [Outline] This command selects and prints the inverted characters. Enter it at the beginning of one line. Otherwise, it will be invalid. Erect and inverted characters cannot be mixed in one line.
  • Seite 72 User's Manual [Function] Printing and paper feed [Code] <0A>H [Outline] If the print buffer contains the data, this command will feed the line after printing. If not, the command only feeds the line. [Function] Printing [Code] <0D>H [Outline] This command prints the data. If the DIP switch segments 1 to 6 are set to OFF, the printer will print the data in the print buffer and feed the paper by one line.
  • Seite 73 User's Manual ESC "a" n [Function] Setting the n-line paper feed [Code] <1B>H <61>H n 1 ≤ n ≤ 127 [Range] [Outline] This command feeds the paper by the number of lines specified with n. You can set n = 1 to 127 lines.
  • Seite 74 User's Manual ESC "C" <0> n [Function] Setting the n-inch page length [Code] <1B>H <43>H <0> n 1 ≤ n ≤ 127 [Range] [Outline] This command sets the length of one page to n-inches. [Default] n = 42 [Function]...
  • Seite 75 User's Manual ESC "B" [n]k NUL [Function] Setting the vertical tab position [Code] <1B>H <42>H [n]k <00> 1 ≤ n ≤ 255 [Range] 1 ≤ k ≤ 16 [Outline] This command cancels the already set vertical tab positions and sets new vertical tab positions.
  • Seite 76 User's Manual ESC "O" [Function] Canceling the lower margin [Code] <1B>H <4F>H [Outline] This command deselects the set lower margin. ESC "l" n [Function] Setting the left margin [Code] <1B>H <6C>H n 0 ≤ n ≤ (Right margin - 2)
  • Seite 77 User's Manual [Function] Horizontal tab [Code] <09>H [Outline] This command moves a printing position to the preset next horizontal tab position. This command will be ignored unless there is the next horizontal tab position. CITIZEN...
  • Seite 78 User's Manual ESC "D" [n] k NUL [Function] Setting the horizontal tab position [Code] <1B>H <44>H [n] k <00>H 1 ≤ n ≤ Max. print columns – 1 [Range] 1 ≤ k ≤ 16 [Outline] This command sets the horizontal tab positions. n indicates the number of lines from the head of the line to the horizontal tab setting position;...
  • Seite 79 User's Manual ESC "1" [Function] Setting the 1/9-inch line feed width [Code] <1B>H <31>H [Outline] This command sets the line feed width to 1/9 inch. ESC "2" [Function] Setting the 2/9-inch line feed width [Code] <1B>H <32>H [Outline] This command sets the line feed width to 2/9 inch.
  • Seite 80 User's Manual ESC "K" n1 <0> m1 m2 ... [Function] Specifying the 8-dot standard density bit image [Code] <1B>H <4B>H n1 <00>H m1 m2 ... 1 ≤ n1 ≤ 378/2 [Range] [Outline] This command prints the bit image by the number of data specified with n1. Printing will be unidirectional.
  • Seite 81 User's Manual ESC "L" n1 n2 m1 m2 ... [Function] Specifying the 8-dot double density bit image [Code] <1B>H <4C>H n1 n2 m1 m2 ... 1 ≤ n1 + 256 × 2 ≤ 378 [Range] [Outline] This command prints the 8-dot double density (Half-dot print) bit image. Printing will be unidirectional.
  • Seite 82 User's Manual ESC "h" n [Function] Specifying/Canceling the double height character [Code] <1B>H <68>H n [Outline] The data following this command is printed in double height characters, except the bit image mode <ESC> "K" and <ESC> "L". In combination with the <SO> command, this command can print double height, double width characters.
  • Seite 83 User's Manual ESC "&" <O> n1 n2 m0 m1 m2 m3 m4 m5 m6 m7 m8 m9] n2 - n1 + 1 [Function] Defining the download character set [Code] <1B>H <26>H <00>H n1 n2 [m0 m1 ... m5 m6 m7 m8 m9] n2 - n1 + 1 32 ≤...
  • Seite 84 User's Manual ESC "%" n [Function] Specifying/Canceling the download character set [Code] <1B>H <25>H n [Outline] This command selects/deselects the download character set. The download characters cannot be printed by simply defining them with the above-mentioned ESC & 0 command.
  • Seite 85 User's Manual ESC BEL n1 n2 [Function] Setting the external device drive pulse width [Code] <1B>H <07>H n1 n2 1 ≤ n1 ≤ 127 [Range] 1 ≤ n2 ≤ 127 [Outline] This command sets the power-on time to drive an external device(Cash drawer).
  • Seite 86 User's Manual [Function] Driving command B for drawer-1 [Code] <1C>H [Outline] This command drives the drawer connector no. 2 pin under the condition set with the <ESC><BEL> n1 n2 command. [Function] Driving command for drawer-2 [Code] <1A>H [Outline] As soon as this command is received, the drawer connector no. 5 pin is driven. The power-on time is 200 ms ON and 200 ms OFF stationary.
  • Seite 87 User's Manual [Function] Canceling the print data [Code] <18>H [Outline] This command clears the input buffer and print buffer. In the STX-EXT mode of the serial interface printer, the command clears the data in the data buffer and ends the STX-ETX mode.
  • Seite 88 User's Manual ESC "U" n [Function] Selecting the Unidirectional/Bidirectional print mode [Code] <1B>H <55>H n 0 ≤ n ≤ 255 [Range] [Outline] This commands selects or deselects unidirectional print. n0 = 0 Bidirectional print n0 = 1 Unidirectional print ESC "@"...
  • Seite 89 User's Manual [Function] Enquiry [Code] <05>H [Outline] This command is valid only for the serial interface. The printer sends the status information. If this command is entered after receiving the text information in the STX- ETX mode, the printer will send the status information and check byte.
  • Seite 90 User's Manual [Function] Text start [Code] <02>H [Outline] This command is valid only for the serial interface. It effectuates the STX-ETX mode. [Function] Text end [Code] <03>H [Outline] This command is valid only for the serial interface. It ends the STX-ETX mode and prints the data.
  • Seite 91 User's Manual * ETX-STX Mode STX/ETX Mode Start Sends ENQ Sends ENQ Receives Status Receives Status Receives Check Byte Data Buffer Empty ? Status Error ? Sends STX Check Byte = Test Byte ? Odd Parity Check ? Sends ETX...
  • Seite 92 User's Manual ESC "t" n [Function] Selecting the character code table [Code] <1B>H <74>H n 0 ≤ n ≤ 255 [Range] [Outline] This command selects Page-n of Character Code Table. [Default] Depends on DIP switch setting. Character Code Table...
  • Seite 93 User's Manual ESC "/" n "data" CR or LF [Function] Defining the message [Code] <1B>H <2F>H n "data" CR or LF 1 ≤ n ≤ 10 [Range] [Outline] This command can define up to a 50-byte message in one line. If the value of n is specified beyond the range, the data following n will be treated as the print data.
  • Seite 94 User's Manual ESC DC2 n1 n2 [Function] Deleting the download character, message, bit image [Code] <1B>H <12>H n1 n2 0 ≤ n1≤ 3 [Range] 0 ≤ n2 (Specify 0 at n1 = 0) (1 ≤ n2 ≤ 10 at n1 = 1) (32 ≤...
  • Seite 95 User's Manual GS "*" n1 n2 [d] n1 × n2 × 8 [Function] Defining the download, bit image <1D>H <2A>H <n1> <n2> [<d>] n1 × n2 × 8 [Code] 1 ≤ n1 ≤ 45 0 ≤ n2 ≤ 24 [Range] Note) Take care that the number of data(n1×n2×8) is equal to or smaller than 2,048.
  • Seite 96 User's Manual GS / m [Function] Printing the download, bit image [Code] <1D>H <2F>H m 0 ≤ m ≤ 255 [Range] [Outline] This command prints the bit image saved in the number specified with m. [Caution] If the print buffer contains the data, this command will be ignored. If the bit image has not been saved in the specified number, this command will be ignored.

  • Seite 97: Esc/Pos Commands

    User's Manual 13.3 ESC/POS Commands 13.3.1 Command List Command Function Code Page Horizontal tab Printing and paper feed Printing ESC " " n Setting the character right space 1BH 20H n ESC ! n Setting print mode batch 1BH 21H n...
  • Seite 98 User's Manual Details [Function] Horizontal tab [Code] <09>H [Outline] This command moves a printing position to the next horizontal tab position. If the next horizontal tab position is not set, this command will be ignored. [Caution] The horizontal tab position is set by <ESC> D. Initial setting of the horizontal tab position is every 8 characters (9th, 17th, 25th culomns, and so on) of the 7×9 font.
  • Seite 99 User's Manual [Function] Printing [Code] <0D>H [Outline] This command prints the data. If the DIP switch segments 1 to 6 are set to OFF, the printer will print the data in the print buffer and feed the paper by one line. If they are set to ON, the printer will print the data in the print buffer and will not feed the paper.
  • Seite 100 User's Manual ESC "!" n [Function] Setting the print mode batch [Code] <1B>H <21>H n 0 ≤ n ≤ 255 [Range] [Outline] Sets the print mode. "n" (Each bit) has the following meanings. Values Function − − Undefined −...
  • Seite 101 User's Manual ESC "%" n [Function] Specifying/Canceling the download character set [Code] <1B>H <25>H n 0 ≤ n ≤ 255 [Range] [Outline] This command selects/deselects the download character set. n is valid only for the least significant bit. Setting n0 = 1 selects the download character set.
  • Seite 102 User's Manual ESC "&" s n m [a[p] s × a]m - n + 1 [Function] Defining the download character set <1B>H <26>H s n m [a[p] ... <ps × a>] m - n + 1 [Code] [Range] s = 2 32 ≤...
  • Seite 103 User's Manual ESC "*" m n1 n2 [d] n1 + 256 × n2 [Function] Specifying the bit image mode [Code] <1B>H <2A>H m n1 n2 [d] n1 + 256×2 [Range] m = 0, 1 0 ≤ n1 ≤ 255 0 ≤...
  • Seite 104 User's Manual ESC "2" [Function] Setting the 1/6-inch line feed width [Code] <1B>H <32>H [Outline] This command sets the line feed width to 1/6 inch. ESC "3" [Function] Setting the line feed width in minimum pitch increments [Code] <1B>H <33>H [Outline] This command sets the line feed width to n/18 inch.
  • Seite 105 User's Manual ESC "D" [n]k NUL [Function] Setting the Horizontal tab position [Code] <1B>H <44>H [n]k <00>H 1 ≤ n ≤ 255 [Range] 0 ≤ k ≤ 32 [Outline] This command sets the horizontal tab position. n denotes the number of columns from the head of the line to the horizontal tab setting position and equals the set column position - 1.
  • Seite 106 User's Manual ESC "R" n [Function] Selecting the international character set [Code] <1B>H <52>H n 0 ≤ n ≤ 10 [Range] [Outline] This command selects the international characters according to the value of n. Character Set Character Set U.S.A.
  • Seite 107 User's Manual ESC "U" n [Function] Specifying/Canceling the Unidirectional print mode [Code] <1B>H <55>H 0 ≤ n ≤ 255 [Range] [Outline] This command selects/deselects unidirectional print. n is valid only for the least significant bit. Function Deselects Selects [Caution] If unidirectional print is selected, the printer will print from the left to the right.
  • Seite 108 User's Manual ESC "c" "5" n [Function] Selecting the panel switch enable/disable [Code] <1B>H <63>H <35>H n 0 ≤ n ≤ 255 [Range] [Outline] This command enables/disables the panel switches. n is valid only for the least significant bit.
  • Seite 109 User's Manual ESC "p" m n1 n2 [Function] Specifying the pulse generation [Code] <1B>H <70>H m n1 n2 0 ≤ m ≤ 1 [Range] 0 ≤ n1 ≤ n2 ≤ 255 [Outline] This command outputs the signals specified with n1 and n2 to the connector pins.
  • Seite 110 User's Manual ESC "r" n [Function] Selecting the printing color [Code] <1B>H <72>H n [Range] n = 0, 1 [Outline] This command selects a print color for each line. Setting n = 0 selects black. Setting n = 1 selects red.
  • Seite 111 User's Manual ESC "u" n [Function] Sending the status for peripheral device [Code] <1B>H <75>H n [Range] n = 0 [Outline] This commands sends the status of the connector no. 3 pin. Connector Pin Drawer kick-out connector No. 3 pin...
  • Seite 112 User's Manual ESC "v" [Function] Sending the printer status [Code] <1B>H <76>H [Outline] This command sends the printer status. [Caution] This command is valid only for the serial interface. The following table lists the status sent. In case of DTR/DSR control, only one byte will be sent after confirming that the host is ready to receive (DSR signal has the Space status).
  • Seite 113 User's Manual ESC "{ " n [Function] Specifying/Canceling the inverted character print [Code] <1B>H <7B>H n 0 ≤ n ≤ 255 [Range] [Outline] This command selects/deselects inverted print. n is valid only for the least significant bit. Type Deselects the inverted characters.
  • Seite 114 User's Manual ESC DC3 n [Function] Printing the message [Code] <1B>H <13>H n 1 ≤ n ≤ 10 [Range] [Function] This command prints a message. If the value of n is specified beyond the range, the message will not be printed.
  • Seite 115 User's Manual ESC DC2 n1 n2 [Function] Deleting the download character, message, bit image [Code] <1B>H <12>H n1 n2 0 ≤ n1 ≤ 3 [Range] 0 ≤ n2 (Specify 0 at n1 = 0) (1 ≤ n2 ≤ 10 at n1 = 1) (32 ≤...
  • Seite 116 User's Manual GS "*" n1 n2 [d] n1 × n2 × 8 [Function] Defining the download, bit image <1D>H <2A>H <n1> <n2> [<d>] n1 × n2 × 8 [Code] 1 ≤ n1 ≤ 45 [Range] 0 ≤ n2 ≤ 24 Note) Take care that the number of data(n1×n2×8) is equal to or smaller than 2,048.
  • Seite 117 User's Manual GS / m [Function] Printing the download, bit image [Code] <1D>H <2F>H m 0 ≤ m ≤ 255 [Range] [Outline] This command prints the bit image saved in the number specified with m. [Caution] If the print buffer contains the data, this command will be ignored. If the bit image has not been saved in the specified number, this command will be ignored.

  • Seite 118: Character Codes Table

    User's Manual 14. CHARACTER CODES TABLE 14.1 CBM (Domestic) CITIZEN...

  • Seite 119: Cbm (International)

    User's Manual 14.2 CBM (International) CITIZEN...

  • Seite 120: Star (Domestic)

    User's Manual 14.3 STAR (Domestic) CITIZEN...

  • Seite 121: Star (International)

    User's Manual 14.4 STAR (International) CITIZEN...

  • Seite 122: Code

    User's Manual 14.5 Code Page 437 CITIZEN...

  • Seite 123: Katakana

    User's Manual 14.6 Katakana CITIZEN...

  • Seite 124: Code

    User's Manual 14.7 Code Page 850 CITIZEN...

  • Seite 125: Code

    User's Manual 14.8 Code Page 860 CITIZEN...

  • Seite 126: Code

    User's Manual 14.9 Code Page 863 CITIZEN...

  • Seite 127: Code

    User's Manual 14.10 Code Page 865 CITIZEN...

  • Seite 128: Code

    User's Manual 14.11 Code Page 852 CITIZEN...

  • Seite 129: Code

    User's Manual 14.12 Code Page 866 CITIZEN...

  • Seite 130: Code

    User's Manual 14.13 Code Page 857 CITIZEN...

  • Seite 131: Windows Code

    User's Manual 14.14 Windows Code CITIZEN...

  • Seite 132: International Character Codes Table

    User's Manual 14.15 International Character Codes Table CITIZEN...

  • Seite 133: Appendix 1. Block Diagram

    User's Manual APPENDIX 1. BLOCK DIAGRAM OSC16MHz POWER LED Driver Print ERROR LED Head FEED Switch Paper DIP Switch Driver Drawer Driver Moter Driver Interface Parallel (CENTRONICS Based) Printer Serial Mechanism (RS-232C Based) Reset Vp Vcc AC Adapter Vp : For mechanism drive,...

  • Seite 134: Appendix 2. Outline Drawing

    User's Manual APPENDIX 2. OUTLINE DRAWING CITIZEN...
  • Seite 135 User's Manual <<<German>>> CITIZEN...
  • Seite 136 User's Manual <VORSICHT> 1. Bitte lesen Sie die Bedienungsanleitung vor dem Betrieb des Geräts aufmerksam durch und bewahren Sie die Anleitung anschließend für späteres Nachschlagen an einem sicheren Platz auf. 2. Änderungen des Inhalts dieser Anleitung bleiben ohne Vorankündigung vorbehalten.

  • Seite 137: Zu Beachtende Sicherheitsmassregeln

    User's Manual ZU BEACHTENDE SICHERHEITSMASSREGELN Zur Vermeidung von Gefahren gegenüber dem Bediener und anderen Personen und Sachschäden sind die folgenden Vorsichtsmaßregeln unbedingt zu beachten.  Der folgende Text beschreibt das Ausmaß der Gefahren und potentiellen Sachschäden, die durch eine Mißachtung der Bedienungshinweise oder durch die unsachgemäße Handhabung des Geräts entstehen...
  • Seite 138 User's Manual WARNUNG  Beim Betrieb des Geräts sind die nachfolgenden Vorsichtsmaßregeln unbedingt zu beachten. Eine Mißachtung dieser Hinweise kann zu Schäden, Funktionsstörungen, Rauchentwicklung und Brandgefahr durch Überhitzen und zu elektrischen Schlägen führen. Der fortgesetzte Betrieb des Geräts in anormalem Zustand, wie z.B. nach einer Beschädigung, kann Funktionsstörungen, Rauchentwicklung, fremde Gerüche/Geräusche und Brände verursachen.

  • Seite 139: Vorsichtsmassregeln Für Die Aufstellung

    User's Manual VORSICHTSMASSREGELN FÜR DIE AUFSTELLUNG • Das Gerät nicht an Plätzen abstellen oder betreiben, an denen es Feuer, Feuchtigkeit oder direkter Sonnenbestrahlung ausgesetzt ist. Ebenso sind Plätze in der Nähe von Heizkörpern und sonstigen Wärmenquellen zu vermeiden, an denen Umgebungstemperatur und Luftfeuchtigkeit nicht den vorgeschriebenen Betriebsbedingungen entsprechen, sowie Plätze, an denen das Gerät Öl, Metallspänen...

  • Seite 140: Vorsichtsmassregeln Für Die Handhabung

    User's Manual VORSICHTSMASSREGELN FÜR DIE HANDHABUNG Zur Vermeidung von Problemen sind bei der Handhabung des Geräts die folgenden Vorsichtsmaßregeln zu beachten. • Für die Stromversorgung ausschließlich das vorgeschriebene Netzteil verwenden. • Den Druckbetrieb nicht ohne eingelegtes Papier oder ohne Farbband starten, da hierdurch der Druckkopf beschädigt werden kann.

  • Seite 141: Tägliche Wartung

    User's Manual TÄGLICHE WARTUNG • Vor der Wartung zuerst den Drucker ausschalten. • Schmutz und Staub mit einem trockenen, weichen Tuch vom Druckergehäuse abwischen. Bei starker Verschmutzung einen Lappen in Wasser anfeuchten, auswringen und damit abwischen. Hierzu niemals flüchtige organische Lösungsmittel, wie z.B. Alkohol, Terpentin, Trichlorethan, Benzol, Keton oder chemische Staubentfernungsmittel, verwenden.

  • Seite 142: Betrieb

    User's Manual 4. BETRIEB 4.1 Anschluß des Netzteils 1. Den Netzschalter drücken. 2. Den Kabelstecker des Netzteils an die Netzanschlußbuchse an der Rückwand des Druckers anschließen. 3. Um Anschlußunterbrechungen vorzubeugen, den Kabelstecker, wie in der untenstehenden Abbildung gezeigt, mit Drahtklemmen sichern.

  • Seite 143: Anschluß Des Schnittstellenkabels

    User's Manual 4.2 Anschluß des Schnittstellenkabels 1. Den Drucker (einschließlich angeschlossene Geräte) ausschalten. 2. Den Kabelstecker korrekt ausgerichtet (Ober- und Unterseite prüfen) an die Schnittstellenbuchse anschließen. 3. Die Kabelstecker befestigen: • Seriellschnittstelle: durch Festziehen der Schrauben sichern. • Parallelschnittstelle: durch Drehen des Anschlags sichern.

  • Seite 144: Einsetzen Der Farbbandkassette

    User's Manual 4.4 Einsetzen der Farbbandkassette 1. Die Druckerabdeckung aufklappen. 2. Bei schlaffem Farbband den Knopf in Pfeilrichtung drehen, um das Band vor dem Einsetzen der Kassette straff zu wickeln. 3. Die Farbbandkassette zwischen Druckkopfabdeckung und Walze einsetzen und gleichzeitig die Halteklauen in den Halter des Druckers drücken.

  • Seite 145: Einlegen Der Papierrolle

    User's Manual 4.5 Einlegen der Papierrolle 1. Mit den Fingern in die Aussparungen an beiden Seiten der Druckerabdeckung greifen, und die Abdeckung durch Anheben bis zum Anschlag öffnen. 2. Das Ende des Druckpapiers in nahezu rechtem Winkel abschneiden. : • Ausschließlich das vorgeschriebene Druckpapier verwenden.
  • Seite 146 User's Manual : • Schlaffes Druckpapier durch Zurückdrehen der Papierrolle straffen. VORSICHT • Bei schräg eingesetztem Druckpapier den Papier-Freigabehebels drücken und das Papier gerade richten. • Die Druckerabdeckung niemals während des Druckens öffnen, da hierdurch Papierstaus entstehen können. CITIZEN...

  • Seite 147: Entfernen Des Restlichen Druckpapiers

    User's Manual 4.6 Entfernen des restlichen Druckpapiers 1. Die Druckerabdeckung aufklappen. 2. Den Papier-Freigabehebel in Pfeilrichtung drücken und das Rollenpapier herausziehen. VORSICHT : Beim Herausziehen des Druckpapiers (in Vorwärts- oder Rückwärtsrichtung) darauf achten, den Papier-Freigabehebel zu betätigen. 4.7 Beseitigung von Papierstaus 1.

  • Seite 148: Bedienfeld Und Fehleranzeigelämpchen

    User's Manual 4.8 Bedienfeld und Fehleranzeigelämpchen 1. Netzanzeigelämpchen (grün) (POWER) Leuchtet bei eingeschalteter Netzversorgung. 2. Fehleranzeigelämpchen (rot) (ERROR) Leuchtet, wenn das Papier aufgebraucht ist oder ein Fehler im Druckmechanismus oder in der Kommunikations auftritt. <Fehleranzeigen> •Papierende: Wenn sich das Papier dem Ende nähert, erkennt ein Sensor, der sich am Papierweg in der Nähe des Druckkopfes befindet, das Papierende und schaltet das LED-...

  • Seite 149: Betriebsfluß Beim Einschalten

    User's Manual 4.9 Betriebsfluß beim Einschalten Einschalten Feed SW ? "Pufferdaten löschen" Ja (FEED SW) und Pufferdaten vergrößerter Rot-Druck NEIN 1 Sek. vergangen 1 Sek. vergangen FEED SW ? FEED SW ? (FORTSETZEN) (ERNEUT) Druckt "=Hexadecimal Dum=" Testdruck Eingabepuffer leer...

  • Seite 150: Dip-Schalter-Einstellung

    User's Manual 5. DIP-SCHALTER-EINSTELLUNG 5.1 Lage der DIP-Schalter (1) Betriebsstrom ausschalten. (2) Ein Kassettenband entfernen. Die DIP-Schalter liegen, wie in der Abbildung gezeigt. (Nur DS1 für Parallel-Schnittstelle vorhanden.) CITIZEN...

  • Seite 151: Dip-Schalter-Einstellungen

    User's Manual 5.2 DIP-Schalter-Einstellungen 1) DIP-Schalter 1 Funktion Bei Auslieferung ab Werk DS1-1 Nein Automatische Schneideinheit DS1-2 Internationale Zeichen AUS *2 ″ DS1-3 Siehe Tabelle unten AUS *2 ″ DS1-4 AUS *2 DS1-5 Verwendetes Papier DS1-6 CR-Modus Siehe Tabelle unten...
  • Seite 152 User's Manual 2) DIP-Schalter 2 Funktion Werksseitige Einstellung DS2-1 Bitlänge 8 Bit 7 Bit DS2-2 Parität Nein DS2-3 Ungerade/Gerade Ungerade Gerade DS2-4 Kommunikationsmodus DTR/DSR XON/XOFF DS2-5 Baudrate ″ DS2-6 Siehe Tabelle unten ″ DS2-7 − − DS2-8 Nicht verwendet...

  • Seite 153: Einstellung Der Vorwahl-Jumperstecker

    User's Manual 6. EINSTELLUNG DER VORWAHL-JUMPERSTECKER 6.1 Lage der Vorwahl-Jumperstecker (1) Betriebsstrom ausschalten. (2) Ein Kassettenband entfernen. (3) Die Oberabdeckung entfernen. Der Vorwahl-Jumperstecker liegt, wie in der Abbildung unten gezeigt. Serielle Schnittstelle Parallele Schnittstelle 6.2 Vorwahl-Jumperstecker-Tabelle Seriell Modus STAR...

  • Seite 154: Methode Für Moduseinstellung

    User's Manual 7. METHODE FÜR MODUSEINSTELLUNG Dieser Drucker hat die Modi CBM, STAR und ESC/POS. Jeder gewünschte Modus kann gewählt und nach Bedarf eingestellt werden. (1) Einstellmethode • Siehe 5. DIP-SCHALTER-EINSTELLUNG • Unter bezug auf die Einstellungen der DIP-Schalter-Segmente 1-9 und 1-10 und die der Vorwahl- Jumperstecker jeden Modus einstellen.

  • Seite 155: Wartung Und Dienst

    User's Manual 12. WARTUNG UND DIENST Bitte wenden Sie sich an die folgenden Stellen für weitergehende Informationen. Nordamerika Andere Gebiete CBM America Corporation Japan CBM Corporation Service Center Information Systems Division 363 Van Ness Way CBM Bldg., 5-68-10, Nakano...
  • Seite 156 Information Systems Division CBM Bldg., 5-68-10, Nakano, Nakano-ku, Tokyo 164-0001, Japan Head Office Tel: (+81-3) 5345-7540 Fax: (+81-3) 5345-7541 02-981210-0500-0472-0160-1500 Printed in Japan...
