Important.
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety information with due care. Keep these
operating instructions in a safe place so that the
information is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and the safety information as
well. We cannot accept any liability for damage or
accidents which arise due to a failure to follow these
instructions and the safety information.

1. Safety information

Please refer to the booklet included in delivery for the
safety information.
CAUTION
Read all the safety regulations and instructions.
Any errors made in following the safety information
and instructions set out below may result in an electric
shock, fire and/or serious injury.
Keep all safety information and instructions in a
safe place for future use.
Safety devices
When working with the equipment, the appropriate
plastic guard hood for cutting blade mode or cutting
line mode must be fitted to prevent objects being
thrown out by the equipment. The integrated blade in
the cutting line guard hood automatically cuts the line
to the optimum length.
2. Technical Manual (Fig. 1-13)
1. Guide pin adapter
2. Guide pin
3. Operating handle
4. Starter cable
5. Choke lever
6. Gas tank
7. Fuel pump (primer)
8. Air filter housing cover
9. ON-OFF switch
10. Screwdriver
11. Throttle lever
12. Locking knob for throttle lever
13. Spool with nylon line
14. Nylon line protective hood
15. Cutting blade safety cover
16. 4 ea. screws M5 (25 mm)
17. Carrying strap
18. Cutting blade
18
19. Operating handle retainer
20. 4 ea. screws M5 (20 mm)
21. 4 ea. nuts M5
22. Driving plate
23. Pressure plate
24. Pressure plate cover
25. Nut M10 (left-hand thread)
26. Combined oil/petrol cylinder
27. Spark plug wrench
28. Open-ended spanner 8/10mm
29. Allen wrench 4 mm
30. Allen wrench 5 mm
31. 2 ea. Tie wraps
32. Knurled screw M6
33. Nut M6
34. Washer Ø 6mm
35. Air filter
36. Spark plug boot

3. Items supplied

Open the packaging and take out the equipment
n
with care.
Remove the packaging material and any
n
packaging and/or transportation braces (if
available).
Check to see if all items are supplied.
n
Inspect the equipment and accessories for
n
transport damage.
If possible, please keep the packaging until the
n
end of the guarantee period.
IMPORTANT
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
foils or small parts.
There is a danger of swallowing or suffocating!
Petrol scythe mower
n
Guide pin
n
Operating handle
n
Operating handle retainer
n
4 ea. screws M5 (20 mm)
n
4 ea. nuts M5
n
Carrying strap
n
4 ea. screws M5 (25 mm)
n
Trimming blade
n
Spool with nylon line
n
Driving plate
n
Pressure plate
n
Pressure plate cover
n
Nut M10 (left-hand thread)
n
Combined oil/petrol cylinder
n
Spark plug wrench
n
Open-ended spanner 8/10mm
n
