CLEANING AND MAINTENANCE

The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tighly connected and must not
be corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use alcohol or
solvents!
The interior of the device should be cleaned at least annually using a vacuum-cleaner or an air-jet.
There are no serviceable parts inside the device except for the lamp. Maintenance and service operations
are only to be carried out by authorized dealers.
Please refer to the instructions under "Installing/Replacing the lamp".
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only
in order to avoid hazards.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Fitting lamp:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Dimensions (LxWxH):
Weight (without lamp):
Accessories
TPC-10 Coupler, black
PAR-64 240V/1000W GX16d VNSP 300h H
PAR-64 240V/1000W GX16d NSP 300h H
PAR-64 240V/1000W GX16d MFL 300h H
A1 230V/500W GY-9,5 75h
Safety plug plastic, black
Safety bond AG-5 3x600mm up to 5kg
Please note: All information is subject to change without prior notice. 10.06.2015 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
(steady state):
C
230 V AC, 50 HZ ~
max. 1000 W
max. 230 V/1000 W PAR-64 lamps with socket GX-16d
max. 230 V/500 W using Raylight with socket GY-9,5
45° C
305° C
0.5 m
3 m
425 x 265 x 270 mm
1.5 kg
No.:
59006858
88147005
88147105
88147205
88384005
3023610A
58010360
16/16 00091983, Version 2.1
