Connection With The Mains; Operation - EuroLite PAR-64 Spot Long mit PAR-Safe Bedienungsanleitung

The maximum drop distance must never exceed 20 cm.
A safety bond which already held the strain of a crash or which is defective must not be used again.
Adjust the desired inclination-angle via the mounting-bracket and tighten the fixation screws.
Before taking into operation for the first time, the installation has to be approved by an expert!
The spot may only be operated when in accordance with the allowable position for use. Please ensure, that
the angle of inclination is set within the following parameters:
Adjust the desired inclination-angle via the mounting-bracket and tighten the fixation screws.

Connection with the mains

The electric connection must only be carried out by a qualified electrician!
In order to connect the device to the mains, you have to install a power-plug.
The occupation of the connection cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
Connect the device to the mains with the power-plug.
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Before taking into operation for the first time, the installation has to be approved by an expert!

OPERATION

After you connected the spot to the mains, you can control the spots via your lighting controller.
DANGER TO LIFE!
DANGER TO LIFE!
International
L
N
DANGER TO LIFE!
15/16 00091983, Version 2.1
