Touch-it Automation glass Hygienic
Bedienungsanleitung
3

Hardwarebeschreibung

3.1 Geräteschnittstellen
USB Host 2.0 (Typ A)
PIN
1
2
3
4

Tabelle 8: Pinbelegung USB 2.0

USB Host 3.0 (Typ A)
PIN
1
2
3
4
5
6
7
8
9

Tabelle 9: Pinbelegung USB 3.0

Ethernet
PIN
1
2
3
4
5
6
7
8

Tabelle 10: Pinbelegung Ethernet

PA10008463
Funktion Beschreibung
VBUS USB VCC
D- USB Data-
D+ USB Data+
GND USB Ground
Funktion Beschreibung
VBUS USB VCC
D- USB Data-
D+ USB Data+
GND USB Ground
StdA_SSRX- SuperSpeed transmitter differential pair
StdA_SSRX+ SuperSpeed transmitter differential pair
GND_DRAIN Ground for signal return
StdA_SSTX- SuperSpeed receiver differential pair
StdA_SSTX+ SuperSpeed receiver differential pair
Funktion Beschreibung
D1+ Transmit Data +
D1- Transmit Data -
D2+ Receive Data+
D3+ Bidirectional +
D3- Bidirectional -
D2- Receive Data -
D4+ Bidirectional +
D4- Bidirectional -
12 / 35 Apr. 2022, Revision 01
