Gude Expert Net Control 2111 Anleitung Seite 106

Spezifikationen
input
input {port_num} state show
input all state {MODE0=0|MODE1=1|MODE2=2}
show
input {port_num} name set "{name}"
input {port_num} name show
input {port_num} invert enabled set {off=0|on=1} inverts input on/off
input {port_num} invert enabled show
input {port_num} label {LOW=0|HIGH=1} set
"{name}"
input {port_num} label {LOW=0|HIGH=1} show
input {port_num} events set {off=0|on=1}
input {port_num} events show
input {port_num} events type set
"{EVT_SYSLOG=0,EVT_SNMP=1,EVT_EMAIL=2,E
VT_SMS=3,EVT_GSMEMAIL=4,EVT_BEEPER=5,E
VT_DISPLAY=6,EVT_CONSOLE=7}"
input {port_num} events type show
input {port_num} phonebook sms events set
"{1..20}"
input {port_num} phonebook sms events show
input {port_num} {LOW=0|HIGH=1} port set
{port_num}
input {port_num} {LOW=0|HIGH=1} port show
input {port_num} {LOW=0|HIGH=1} state set
{OFF=0|ON=1|DISABLED=2}
input {port_num} {LOW=0|HIGH=1} state show
input volt3 state show
input volt12 state set {OFF=0|VLO=1|VHI=2}
input volt12 state show
ip4
ip4 hostname set "{name}"
ip4 hostname show
ip4 address set "{ip_address}"
ip4 address show
ip4 netmask set "{ip_address}"
ip4 netmask show
ip4 gatew ay set "{ip_address}"
ip4 gatew ay show
ip4 dns set "{ip_address}"
ip4 dns show
ip4 dhcp enabled set {OFF=0|ON=1}
ip4 dhcp enabled show
ip6
ip6 enabled set {OFF=0|ON=1}
ip6 enabled show
ip6 routadv enabled set {OFF=0|ON=1}
ip6 routadv enabled show
ip6 dhcp enabled set {OFF=0|ON=1}
ip6 dhcp enabled show
ip6 address show
ip6 gatew ay show
ip6 dns show
ip6 manual enabled set {OFF=0|ON=1}
ip6 manual enabled show
ip6 manual address {1..4} set "{ip_address}"
ip6 manual address {1..4} show
ip6 manual gatew ay set "{ip_address}"
ip6 manual gatew ay show
ip6 manual dns {1..2} set "{ip_address}"
ip6 manual dns {1..2} show
Expert Net Control 2111/2191
enters cmd group "input"
show s input state
show s input state of all ports in 3 different view
modes
sets sensor name to label
show s label of sensor
show s if input inverted
sets input low /high text
show s inputs low /high text
enables input events on/off
show s if input events are enabled
enables different event types
show s w hat event types are enabled
sets for w hat phonebook entries SMS are sent
show s for w hat phonebook entries SMS are sent
sets Port for Pow er Port Sw itching actions
show s Port for Pow er Port Sw itching actions
sets Port state for Pow er Port Sw itching actions
show s Port state for Pow er Port Sw itching
actions
show s state of 3V input voltage {ON=1|VERR=3}
sets state of 12V input voltage
show s state of 12V input voltage {OFF=0|VLO=1|
VHI=2|VERR=3} incl possible error condition
enters cmd group "ip4"
sets device hostname
show s device hostname
sets IPv4 address
show s IPv4 address
sets IPv4 netmask
show s IPv4 netmask
sets IPv4 gatew ay address
show s IPv4 gatew ay address
sets IPv4 DNS server address
show s IPv4 DNS server address
enables IPv4 DHCP on/off
show s IPv4 DHCP state
enters cmd group "ip6"
enables IPv6 on/off
show s if IPv6 is enabled
enables IPv6 router advertisement
show s IPv6 router advertisement state
enables IPv6 DHCP on/off
show s if IPv6 DHCP is enabled
show all IPv6 addresses
show all IPv6 gatew ays
show all IPv6 DNS server
enables manual IPv6 addresses
show s if manual IPv6 addresses are enabled
sets manual IPv6 address
show s manual IPv6 address
sets manual IPv6 gatew ay address
show s manual IPv6 gatew ay address
sets manual IPv6 DNS server address
show s manual IPv6 DNS server address
4
3
3
3
3
3
3
3
3
3
4
4
4
3
3
3
3
106
