Gude Expert Net Control 2111 Anleitung Seite 104

Spezifikationen
extsensor {port_num} {sen_type} {sen_field} hyst
set {num}
extsensor {port_num} {sen_type} {sen_field} hyst
show
extsensor {port_num} {sen_type} {sen_field}
publish mode set {NONE=0|INTERVAL=1|
DELTA=2|INTERV_DELTA=3}
extsensor {port_num} {sen_type} {sen_field}
publish mode show
extsensor {port_num} {sen_type} {sen_field}
publish mqtt retain set {OFF=0|ON=1}
extsensor {port_num} {sen_type} {sen_field}
publish mqtt retain show
extsensor {port_num} {sen_type} {sen_field}
publish timer set {num_secs}
extsensor {port_num} {sen_type} {sen_field}
publish timer show
extsensor {port_num} {sen_type} {sen_field}
publish delta set {float}
extsensor {port_num} {sen_type} {sen_field}
publish delta show
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port set {port_num}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port show
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state set {OFF=0|ON=1|
DISABLED=2}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state show
extsensor period set {24H=0|12H=1|2H=2|1H=3|
30MIN=4}
extsensor period show
gsm
gsm enabled set {OFF=0|ON=1}
gsm enabled show
gsm pin set "{pin_num}"
gsm pin show
gsm phonenum set "{phone_num}"
gsm phonenum show
gsm admin sms set "{phone_num}"
gsm admin sms show
gsm admin sms enabled set {OFF=0|ON=1}
gsm admin sms enabled show
gsm admin email enabled set {OFF=0|ON=1}
gsm admin email enabled show
gsm admin email set "{email_addr}"
gsm admin email show
gsm dtmf sms pin enabled set {OFF=0|ON=1}
gsm dtmf sms pin enabled show
gsm dtmf sms master pin set "{pin_num}"
gsm dtmf sms master pin show
gsm phonebook check set {OFF=0|ON=1}
gsm phonebook check show
gsm freecall enabled set {OFF=0|ON=1}
gsm freecall enabled show
gsm admin only set {OFF=0|ON=1}
Expert Net Control 2111/2191
sets hysterese value for sensor
show s hysterese value for sensor
sets publish mode
show s publish mode
sets mqtt retain
show s if mqtt retain set
sets publish time interval
show s publish time interval
sets publish delta value
show s publish delta value
sets Port for Pow er Port Sw itching actions
show s Port for Pow er Port Sw itching actions
sets Port state for Pow er Port Sw itching actions
show s Port state for Pow er Port Sw itching
actions
sets sensor Min/Max measurement period
show s sensor Min/Max measurement period
enters cmd group "gsm"
activates the built-in GSM module
show s if the built-in GSM module is enabled
sets PIN and sw itches the PIN request on
show s the PIN of the SIM card
sets the phone number of the SIM card
show s the phone number of the SIM card
sets phone number for SMS status changes
show s phone number for SMS status changes
enables status changes sent via SMS
show s if status changes via SMS are enabled
enables status changes sent via email
show s if status changes via email are enabled
sets status email recipient address
show s status email recipient address
enables necessary pin for port changes
show s if pin is needed for port changes
sets master pin for port changes
show s master pin for port changes
only allow access to calls that correspond to
phonebook entries
show s if phonebook change enabled
enable functions associated w ith incoming phone
numbers
show if freecall enabled
only allow caller actions from the admin
phonenum
6
6
6
6
6
6
104
