4.1 Dimensional data

fig. 4
160
Ø
fig. 6
User, Installations and Maintenance Manual
620
Ø
160
Ø
380
fig. 5
MODEL Ø EKHHE200PCV37 EKHHE260PCV37 EKHHE200CV37 EKHHE260CV37 UM
A
1"G 250 250
B - 490 493
C 1/2"G 600 600
D
- 705 785
E 1"G 876.5 1162
G - 1142 1427
H
- 1607 1892
I 3/4"G 250 250
L 3/4"G 599 600
M 3/4"G 705 735
N 3/4"G 877 1162
O* 1/2"G 976 1261
P - 1073 1358
*O - Outlet connection in plastic material
250 250 mm
/ / mm
600 600 mm
705 785 mm
876.5 1162 mm
1142 1427 mm
1607 1892 mm
/ / mm
/ / mm
705 735 mm
877 1162 mm
976 1261 mm
1073 1358 mm
Page 11
