2 - CONTROL PANEL

11
Fig. 2.1
12 13
9 8
10 7 6 5 4 2 1
3
CONTROL PANEL - Controls description
1. Front right cooking zone control knob
2. Rear right cooking zone control knob
3. Central cooking zone control knob
4. Rear left cooking zone control knob
5. Front left cooking zone control knob
6. Multifunction oven switch knob (left oven)
7. Multifunction oven thermostat knob (left oven)
8. Conventional oven thermostat knob (right oven)
9. Conventional oven switch knob (right oven)
10. Electronic programmer (left main oven only)
Pilot lamps:
11. Conventional oven temperature indicator light (right oven)
12. Multifunction oven temperature indicator light (left oven)
13. Ceramic hob ON indicator light
