When installing, simple fix all screws first, then tighten the screws when the installation of
frame is done.
NO.
1
2
3
4
5
6
7
8
9
10
11
1. Put the machine flat on the ground and stand the columns and flip the console with the direction
shown in the picture below. (Note: 2 or more people are required)

3. Installation Instructions

Name
Complete Machine
6mm inner hexagon wrench
5mm inner hexagon wrench
Combination wrench
Safety key
Silicone oil
MP3 cable
Screw M6*12
Screw M8*25
Plum knob(M10*20)
User's manual
QTY
1PC
1PC
1PC
1PC
1PC
1PC
1PC
4PCS
2PCS
1PC
1PC
5
