TECHNICAL
- Input Sensitivity/Impedance
- Rated Output
- Direct Output
- A.T.T Step (option)
- Frequency response
- Signal to noise ratio(1KHz)
- T.H.D
- Tone Control
- Power Consumption
- 1/8 Power Current draw 120V/230V CPA-1200: 1.6A/0.8A
- 1/3 Power Current draw 120V/230V CPA-1200: 2.4A/1.2A
- Rated Power Current
draw 120V/230V
GENERAL
- Power Source(Option)
- Dimensions (mm)
- Weight (kg/lbs)
NOTE
Specifications and design subject to change without notice for improvements.
10
All manuals and user guides at all-guides.com
CPA-5120C/5240C/5480C
120V/220V/230V/240VAC 50~60Hz
24VDC
430(W) x 133(H) x 352(D)
(inches) 16.9(W) x 5.2(H) x 13.9(D)
CPA-1200 : 14.0/30.9
CPA-2400 : 16.5/36.4
INPUT 1: Mic : -50dBu(2.45mV) 5KΩ BAL
INPUT 2-4: Mic: -50dBu(2.45mV) 2KΩ BAL
Line : -10dBu(245mV)200KΩ UNBAL
INPUT 5-7: AUX: -10dBu(245mV) 5KΩ UNBAL
PACK UNIT: -10dBU(245mV) 10KΩ UNBAL
PRE OUT: 0dBu(775mV) 100KΩ UNBAL
AMP IN: 0dBu(775mV) 10KΩ UNBAL
CPA-1200 : 120W(RMS)
CPA-2400 : 240W(RMS)
CPA-4800 : 480W(RMS)
8 Ω, 100V or 70V
LINE : LESS THAN -3dB(35Hz~19KHz)
MIC : LESS THAN -3dB(200Hz~19KHz)
MIC : MORE THAN 80dB ("A" WEIGHT)
LINE: MORE THAN 70dB ("A" WEIGHT)
LESS THAN 0.5% (1KHz)
BASS : ±10dB at 100Hz
TREBLE: ±10dB at 10KHz
CPA-1200: 350W
CPA-2400: 740W
CPA-2400: 2.8A/1.4A
CPA-2400: 4A/2A
CPA-1200: 3.6A/1.8A
CPA-2400: 6.4A/3.2A
CPA-4800 : 20.0/44.1
CPA-4800: 1480W
CPA-4800: 5.6A/3.2A
CPA-4800: 8.5A/4.7A
CPA-4800: 14.0A/7.5A
