24 V/DC Notstromversorgung. General use Allgemeines VLA-120 C,VLA-240 C have been designed to ensure Die Verstärker VLA-120 C/VLA-240 C wurden speziell für durable performance and reliable operation of sound den dauerhaften Betrieb von Sound Systemen entwickelt. systems.It is best suited for call and message transmis- Sie sind bestens geeignet für die Beschallung von Sport-...
VARIO-LINE VLA-120 C / VLA-240 C MOUNTING MONTAGE Amplifier racking size for VLA series are designed for Die Verstärker VLA- 120 C/VLA-240C sind mit seitlichen standard 19" rack mounting with additional left, right Befestigungwinkeln für den Einbau in 19" Gestelle ge- bracket.
Seite 4
VARIO-LINE VLA-120 C / VLA-240 C AMP SECTION Hauptmerkmale - AUTOMATIC VARIABLE SPEED FAN - Automatische Anpassung der Lüftergeschwindigkeit - OVER CURRENT PROTECTION - Kurzsschlußschutz - OVER HEATING PROTECTION - Überhitzschutz - LOAD SHORT CIRCUIT PROTECTION - Leerlaufschutz - BUILT IN L.P.F. ( LOW PASS FILTER ) CIRCUIT...
Seite 5
VARIO-LINE VLA-120 C / VLA-240 C - REMOTE 2 VOLUME / EQ VOLUME - REMOTE 2 Regler / EQ Regler Remote 2 volume control / EQ control let you adjust input 2 level Remote 2 Regler für Lautstärke und EQ Regler für Tiefen sowie and REMOTE CONTROLLER (VLM-105/205) level.
Seite 6
VARIO-LINE VLA-120 C / VLA-240 C R Ü C K S E I T E 1. MIC PRIORITY SWITCH 1. MIC PRIORITY Schalter These are for priority setting switches for mic 1, 2, 3 to change 3-fach Schalter um die Priorität der Mikrophoneingänge 1 bis 3 priority ranking from No 3 to No 2, turn switch lever to the right.
Seite 7
OUTPUT IMPEDANCE : Impedance : VLA-120C-4 Ohm / 22 V, VLA-240 4 Ohm / 31V 9. TELEPHONE VLA-120 C : 4ohm / 22V, VLA-240 C: 40hm / 31V 9.TELEPHONE - NIGHT RINGER - NIGHT RINGER Anschlußklemmen zurEinspeisung von Klingelsignal z.B. 8 -12V Connect night ringer terminal to telephone LINE.
Seite 8
VARIO-LINE VLA-120 C / VLA-240 C - PRIORITY FUNCTION - PRIORITÄTS FUNKTIONEN When shipped it is factory preset as follows pack signal priority Werkseinstellung des Prioritätsschalters SW305 (hinter Modul- switch (FRONT PCB SW305) : Setting at SLAVE. The following is leerfeldpaneel): "SLAVE".
Seite 9
VARIO-LINE VLA-120 C / VLA-240 C Anwendungs und Einsatzmöglichkeiten - Beispiele...
Seite 10
VARIO-LINE VLA-120 C / VLA-240 C Weitere Einsatzbeispiele * The above is for emergency situation like a fire. First, record * Zur Fernsteuerung von „ALL CALL“ bzw. der Speicherbank 6 des alert voice message to the memory bank M6 in the DM-10A (Di- DM-10A (Jumper MS 2 auf „Priorität“).
Seite 11
VARIO-LINE VLA-120 C / VLA-240 C Kaskadierung mit weiteren Verstärkern 1. TALK When pressing „TALK“ MIC signal is activated and make input of DC 24V from the crew terminal NO. 2 of main amplifier and priority is activated. 2. DIN JACK This consists of 7 pins use shield cable for microphone.
Seite 12
VARIO-LINE VLA-120 C / VLA-240 C Remote Microphone VLM-105 Remote Microphone VLM-205 (identisch mit VLM-105, jedoch mit Fernbedienung für Digital Massage JDM-10A) 1. POWER (STATUS INDICATOR) 1. POWER Diode zeigt Betriebsbereitschaft an Turn on the power, LED indicator lights. 2. SEND 2.
Seite 15
VARIO-LINE VLA-120 C / VLA-240 C NOTES...
Seite 16
VLA-120 C / VLA-240 C Electromagnetic compatibility and low-voltage guidelines: RCS leaves all devices and products, which are subject to the CE guidelines by certified test laboratories test. By the fact it is guaranteed that you may sell our devices in Germany and in the European Union domestic market without additional checks.
