Inserting The Tool And Mounting On The Driven Tool - Rego-Fix Recool Wartungs- Und Betriebsanleitung

3. Insert groove of the collet into eccentric ring of reCool
in the direction of the arrow until it clicks in.
Improper assembly can result in bad runout of the collet and may result in the damage to reCool
Only mount reCool
into the reCool
®
reCool is not to be used with sealed collets!
®

3.3 Inserting the tool and mounting on the driven tool

1. Insert cutting tool into reCool
Insert tool from the front, otherwise the o-ring may be damaged in the sealing disk.
26
Collet groove
Eccentric ring
Mark on bottom
with correctly inserted collets! Never place the collet into the holder without first assembling
®
nut.
then assemble on to the driven head.
®
at the mark on the bottom of the nut. Push collet
®
.
®
