3.2 Preparation of reCool

If reCool is used without a sealing or flush disk the unit will not provide the desired cooling.
®
®
1. Insert the small diameter of the DS / KS disk into the center of reCool
apply even pressure until the disk is properly seated into the nut. The mar-
kings should be visible from the inside.
Sealing disk
Marking
2. Screw in the supplied M5
Maximum torque: 4 Nm
//
The connection can be chosen depending on the roteting direction and speci-
fic application.
Coolant flush disk
Marking
and
®
25
