Main Functions - air&me ROHAN Bedienungsanleitung

COMPONENTS (SEE PAGE 2)
Movable flap
1
LED bar
2
Air outlet
3
Water tank lid
4
Water tank handle
5
Water tank
6
Water level control
7
Handle
8
Control panel
9
Front side of the appliance
10
CONTROL PANEL (SEE PAGE 3)
[ Timer ] button
A
[ Inside drying of the appliance ] button
B
[ Movable flap ] function
C
[ Speed ] button
D
Full tank indicator
E
Digital display
F
[ Humidity rate ] adjustment button
G
OPERATING INSTRUCTIONS
1. Plug the appliance.
• All luminous indicators of the control panel light for 1 second and then turn off.
• At the same time, the appliance produces a sound signal and the movable flap opens
and then closes.
• When the appliance is operational, the digital display indicates the ambient humidity rate.
2. Press the ON/OFF button ( ) to turn the appliance on. The movable flap opens and the fan
L
turns on at low speed [ LOW ].
3. Press the ON/OFF button again to turn the appliance off: the movable flap comes back to
its initial position and the appliance stops completely.
20
Rear side of the appliance
11
Removable pre-filter
12
Plug of the continuous drainage hole /
13
Lift pump outlet
Power cord storage
14
Multidirectional casters
15
Power cord
16
Continuous drainage hose (60 cm)
17
Lift pump hose (2 m)
18
[ Lift pump ] function
H
[ Mode ] button
I
[ Child safety ] button
J
[ LED display ] function
K
ON/OFF button
L
Wi-Fi connection indicator
M

MAIN FUNCTIONS

[ TIMER ] BUTTON
A
• By pressing this button several times, you can select the operating time from 1 to 24 hours.
A long press of the button allows you to quickly scroll through the numbers on the screen.
• Once the operating time is set, you can release the button: the digital display indicates
the ambient humidity rate, the luminous indicator of the [ Timer ] button lights and the
dehumidifier turns on. It automatically stops at the end of the preset time.
• To deactivate this function, press the button twice in a row when the digital display
indicates the ambient humidity rate.
[ INSIDE DRYING OF THE APPLIANCE ] BUTTON
B
• By pressing this button, you can start the procedure for the inside drying of the dehumidifier:
the luminous indicator lights and the digital display indicates [ CL ]. This process of drying
is very useful before long time storage because it prevents the formation of mould inside
the appliance.
• The process takes about 1 hour:
– The dehumidifier starts in high air speed (HIGH) and releases air continuously for 30
minutes.
– Then, the dehumidifier works in a lower air speed (LOW) for 20 minutes.
– Finally, the appliance comes back in "standby" mode.
• To deactivate this function, press the button again: the luminous indicator turns off.
[ SPEED ] BUTTON
D
By pressing this button several times when AUTO or CONTINUOUS modes are selected, you
can adjust the air flow produced by the appliance selecting between one of the two
modes: LOW (low air flow) or HIGH (strong air flow).
[ HUMIDITY RATE ] BUTTON
G
• By pressing this button several times, you can define the humidity rate of the air that you
want to reach between 30 and 80% (the adjustment is made in 5% steps).
• When the ambient air humidity is lower than the preset humidity rate, the appliance
stops working. When the ambient air humidity is higher than the preset humidity rate, the
appliance automatically restarts.
Be careful, this function is only available in AUTO mode.
[ MODE ] BUTTON
I
This button enables you to choose between two operating modes:
• AUTO Mode: If the humidity rate in the air is higher than the preset rate, the compressor
starts and the fan runs at the preset speed.
On dehumidifiers ROHAN with serial number CF01591 or earlier, if the humidity level in the
air is lower than the preset level, the compressor stops and ONLY the fan runs.
On dehumidifiers ROHAN with serial number CF01652 or later, if the humidity level is lower
than the preset level, the compressor AND the fan will stop.
• CONTINUOUS Mode: Regardless of the humidity rate in the room, the compressor starts
and the fan runs at the preset speed.
Be careful, the build-in hygrostat in the appliance has a margin of error of ± 5%.
21
