Installing the refrigerator
6.7

Securing the refrigerator

!
CAUTION!
Only drill through the receptacles provided, otherwise foamed
components, including cables, can be damaged.
I
NOTE
Attach the side walls or the attached strips so that the screws are
tight, even when under increased loads (while driving).
Proceed as follows (fig. h, page 7):
➤ Move the refrigerator into its final location.
➤ Fasten the four screws (1) through the four plastic washers in the sides of
the refrigerator, and further into the wall.
➤ Put the caps (2) onto the screw heads.
6.8 Reversing the door (RML9430/9431/9435 only)
➤ Remove the control panel.
– RML9430: Unscrew the dials carefully and loosen the screws, fig. i,
page 7
– RML9431/9435: Open the refrigerator door and undo the screws
underneath the control panel, fig. j, page 7
➤ Undo the hinge screw on the top door hinge and keep it in a safe place
(fig. k, page 8).
➤ Lift up the door and remove it (fig. l, page 8).
➤ Undo the two screws on the door lock and remove the door lock (fig. m,
page 8).
➤ Place the door lock on the other side again and tighten it with the two
screws (fig. n, page 8).
➤ Undo the hinge pin (fig. o, page 8) and position it on the other side
(fig. p, page 8).
➤ Turn the door by 180° (fig. q, page 8).
➤ Place the door on the hinge pin.
➤ Replace the control panel and screw it down tightly.
22
