RML9330 – RML9435
6.5 Install the roof vent
No. in
Description
fig. d, page 6
1 Installation frame
2 Hood
➤ Ensure the installation frame is water resistant (fig. e, page 7).
➤ Insert the installation frame and screw it down tightly (fig. e, page 7).
➤ Insert the hood and screw it down tightly (fig. f, page 7).
6.6 Install the flue duct
I
NOTE
Do not install an additional flue stack, as this leads to poor
performance and increases the power consumption of the
refrigerator.
The flue duct is installed at the factory. Follow these steps when you have
removed the flue duct and want to reinstall it (fig. g, page 7):
➤ Place the T-piece (1) on the adaptor (2) and the flue pipe (3).
➤ Direct the T-piece at an angle of 45° towards the rear wall.
➤ Attach the T-piece, adaptor and flue pipe with a screw (4).
EN
All manuals and user guides at all-guides.com
Installing the refrigerator
