Vario RC-Modul Bedienungsanleitung Seite 22

The "Cell voltage" menu displays the actual potential on the salinator cell:
6.
Cell voltage (V)
3,5 V
Read only
The "Salinity" menu displays the actual salt concentration – only when a salinity sensor is attached:
7.
Salinity
4,5 g/l
Read only
Note:
Salt concentration value is displayed directly on the VA SALT SMART chlorinator unit or on the RC module only when a salinity sensor is
attached to the chlorinator unit. With no salinity sensor attached, an "Error" message will be displayed.
The "Warnings" menu shows current active warning notifications:
8.
Warnings
Water temp
Salt low
Low pH
Note:
Warnings are information about operation status of the saltwater chlorinator unit. They indicate whether the parameters are OK or
need adjustment (temperature, salinity, pH, etc.)
The "Alarms" menu shows all active alarm notifications.
9.
Alarms may be deactivated only directly on the salinator unit by pressing "OK").
Alarms
No alarms
Note:
Warnings are information about operation status of the saltwater chlorinator unit. They indicate whether the parameters are OK or
need adjustment (e.g. ORP probe check, unit overheating, cell short-circuit, communication with cell, no flow, etc.)
The "Operation mode" menu allows the user to change the operation mode of the saltwater chlorinator
10.
unit:
Operation mode
> Automatic
Note:
You may adjust the value of the RX parameter exactly the same way. Cancel any unwanted changes by pressing the "ENT/ESC"
button. The default code for parameter changes is "1234". The code may be changed only by a pool professional with a service
module. When a wrong code is entered, changes will not be saved and the unit will return to its default screen.
Select ">Cell-potential" and confirm with "ENT/ESC",
a)
The parameter is only informative - "Read only", it cannot be adjusted.
b)
Select ">Salinity" and confirm with "ENT/ESC",
a)
The parameter is only informative - "Read only", it cannot be adjusted.
b)
Warnings
Salt high
read only
Alarms
No flow
Read only
Select ">Operation mode" and confirm with "ENT/ESC",
a)
Press "SET/SEND" to activate value adjustment,
b)
Press "V" to change mode (Automatic/Manual/Semiautomatic),
c)
Press "ꓥ" to change mode,
d)
Press "SET/SEND" to confirm and send changes to DIN module,
e)
A "Sending" message will appear at the bottom right of the display.
f)
Select ">Active alarms" and confirm with
a)
"ENT/ESC",
The parameter is only informative - "Read only", it
b)
cannot be adjusted.
Select ">Alarms" and confirm with "ENT/ESC",
a)
The parameter is only informative - "Read only", it
b)
cannot be adjusted.
10
