8. The "Time/Date" menu allows the user to set system time and date – important for
proper filtration and dosing/salinator functioning:
Time 14:10
Day 27
Month 07
Year 18
Verification code
0 0 0 0
Wrong code
Note:
Default verification code is 1234. Only an authorized person may change the verification code.
When a wrong code is entered, changes will not be sent to the DIN module and the unit will return to original settings.
9. The "Language" menu allows the user to select the language:
English
10. The "Lights-settings" menu allows the user to choose a lights mode:
Select program
Scene 01
11. The "Dosing ON/OFF" menu allows the user to set the working time of an ON/OFF salt water
chlorinator or a UV lamp with regard to total filtration time:
Filtration 660min
Dosing 100%
[660min]
Time left 470min
IMPORTANT: The Dosing ON/OFF menu will only be available, when the DIN module is configured to this function. Otherwise, the
Attraction 2 will be available on output R2 of the DIN module (instead of Dosing ON/OFF).
Note:
The salinator/dosing unit operation time is directly based on the total filtration time as set in the "AUTO" mode. With filtration running in
any other mode (manual ON/XXCL) this "extra" filtrating time is not calculated in total filtration time used for dosing.
Select ">Time/Date" and press "ENT/ESC" button,
a)
Press "SET/SEND" button to set time and date,
b)
Press "V" to adjust minutes (1 click = +5 min),
c)
Press "ꓥ" to adjust hours (1 click = +1 hour),
d)
Press "<>" to move to next parameter (d/m/y),
e)
Press "V" and "ꓥ" to adjust the selected parameter,
f)
Press "SET/SEND" to confirm and send changes to DIN module,
g)
As a safety precaution, a "Verification code" must be entered.
h)
A "Sending..." message will be displayed; in case wrong code is entered the
i)
"Wrong code" message will appear.
Select ">Language" and confirm with "ENT/ESC",
a)
Press "V" to select language (CZ/EN/HR/FR/DE/ES),
b)
Press "ꓥ" to select language,
c)
Press "SET/SEND" to confirm and send changes to DIN module,
d)
A "Sending..." message will be displayed
e)
Select ">Lights-settings" and confirm with "ENT/ESC",
a)
Press "V" to set mode (Scene/Bright/Next/etc.),
b)
Press "ꓥ" to choose mode,
c)
Press "<>" to adjust value (e.g.. Scene – 02/Bright – 50),
d)
Press "SET/SEND" to confirm and send changes to DIN module,
e)
A "Sending..." message will be displayed.
f)
In main menu, select ">Dosing ON/OFF" and press "ENT/ESC" button,
a)
Press "SET/SEND" button to activate the setting mode and set the salt-
b)
chlorination time in % of filtration time,
Pres "V" to decrease the dosing time (1 click = -25%),
c)
Press "ꓥ" to increase the dosing time (1 click = +25%),
d)
Press "SET/SEND" to confirm and send changes to DIN module,
e)
A "Sending..." message will be displayed.
f)
