3. The "Activate scenes" menu allows the user to activate/deactivate scenes/sequences
programmed via WIFI module or over the Internet:
Activate scenes
Active/Inactive
SEND-Activate/Deactivate
4. The "Filtration" menu allows the user to set up to 4 running cycles within 24 hours:
07:00
12:00
16:00
21:00
Note:
The first cycle starting time (in this case 07:00) also determines the starting time for salinator/dosing unit in automatic operation mode.
When setting the intervals, the first time must be lower than the second; also, you cannot pass midnight within the same interval (e.g.
09:30-06:00). System will not accept such invalid intervals.
5. The "Filtration-mode" menu allows the user to select the operating mode of filtration:
Filtration
[AUTO]
6. The "Lights" and "Att1-4" menus allow the user to set operating timers for these outputs
with a 15 min. step (0-120 for Atr, 0-240/ON for Lights):
Lights
015min
Lights
045min
Lights
075min
Lights
120min
Note: The quick-access F1 button (Lights by default) also allows permanent ON ((000 – ON – 015 – 030 ... 240 min).
7. The "Heating/Cooling" menu allows the user to set the heating / cooling and water temperature:
29°C
Heating
27°C
Cooling
Filtration
Dosing ON/OFF
Temp 22°C
Light.014
Att3 000
Note:
Preset output delay – in this case 8 mins remain to heating power ON (preset delay 10) and allowed operating temperature range are
preset in the system. These technology-protecting parameters can be modified only by authorized person.
The heating priority function can be configured with DIP Switch 8 of the DIN module. With heating priority deactivated, heating/cooling
may be active only when the filtration is running. Also, the operating protections will not be active. Heating is OFF by default (temp
setting), while heating priority default value is ON.
In main menu, select ">Activate scenes" and press "ENT/ESC" button,",
a)
Press "SET/SEND" to activate/deactivate the scene program
b)
In main menu, select ">Filtration" and press "ENT/ESC" button,
a)
Press "SET/SEND" button to activate the timer set mode,
b)
10:00
Press "V" to adjust minutes (1 click = +5 min),
c)
15:00
Press "ꓥ" to adjust hours (1 click = +1 hour),
d)
19:00
Press "<>" to move to the next timer,
d)
23:00
Press "SET/SEND" to confirm and send changes to DIN module,
e)
A "Sending..." message will be displayed.
f)
Select
a)
Press "V" to scroll through modes (AUTO/ZAP/XXCL/VYP),
b)
Press "ꓥ" to select mode,
c)
Press "SET/SEND" to confirm and send changes to DIN module,
g)
A "Sending..." message will be displayed.
h)
a) Select ">Lights" and press "ENT/ESC" button,
Attraction
030min
b) Press "SET/SEND" button to start to set timer,
c) Press "V" to decrease operation time (1 click = -15 min),
Attraction
060min
d) Press "ꓥ" to increase operation time (1 click = +15 min),
e) Press "SET/SEND" to confirm and send changes to DIN module,
Attraction
090min
f) A "Sending..." message will be displayed.
Attraction
000min
In main menu, select ">Temperature" and press "ENT/ESC" button,
a)
Press "SET/SEND" button to start to set temperature,
b)
Press "V" to decrease temperature (1 click = -1°C),
c)
Press "ꓥ" to increase temperature (1 click = +1°C),
d)
Press "<>" to select operation heating or cooling mode,
e)
[ ON]
Press "SET/SEND" to confirm and send changes to DIN module,
f)
[ ON]
A "Sending..." message will be displayed.
g)
[ -05]
Att1 015
Att4 015
">Filtration-mode" and confirm with „ENT/ESC",
5
