Vario RC-Modul Bedienungsanleitung Seite 16

6.2.
Quick-access buttons
Using the F1 / F2 / F3 buttons, you can easily control predefined devices. If the default F1 (Lights) / F2
Attraction) / F3 (Filtration) functions are not up to your choice, the button functions can be
reprogrammed or renamed.
6.2.1. Changing the quick-access button function
With RC in the sleep mode, press and hold "F2" + press " " for at least 3 seconds. The display will light up and
the actual button configuration will be displayed:
Lights F1
Attractions
Filtration
Lights
Attractions F1
Filtration
6.2.2. Renaming the quick-access button functions
You can also rename the functions, should you not like the preset names. Renaming the quick-access functions:
In the sleep mode (display off) press and hold "F3" + press " " for at least 3 seconds. The display will light up
and current configuration will be displayed, e.g.:
>Attract. 1
Attract. 2
Attract. 3
Attract. 4
>Shower
Massage
Attract. 3
Attract. 4
6.3.
Main Menu
5 outputs can be activated in the configuration menu: Filter pump with up to 4 programmable daily cycles
and 2 user regimes, Dosing (ON/OFF) (ON/OFF Salinator / UV Lamp) based on filtration time,
Heating / Cooling function with regard to preset water temperature, Lights and Attraction (e.g.
counterflow) with timer. Selected advanced functions may also be configured:
1. Press the " " button to wake the RC from the sleeping mode.
2. Press the "V" button to enter the configuration menu:
Activate scenes
>Filtration
Filtration-mode
Lights
Heating/Cooling
Attraction
Time/Date
Language
Lights-setting
Dosing ON/OFF
Pumps Module
Silent mode
a)
F2
F3
b)
F3
Note:
If you assign the same function to two buttons, (e.g. Lights for both F1 and F2 buttons),
F2
both buttons will control the same function.
a)
b)
c)
d)
e)
f)
g)
h)
a)
b)
c)
d)
With repeated pressing of the "F1", "F2" or "F3" buttons the new function will
be assigned,
Confirm changes with the "SET/SEND" button, the display will automatically
refresh,
Activate the renaming function by pressing the "ENT/ESC",
Select desired letter using the "V" or "ꓥ" buttons,
Move to next position with "<>",
Use "F1" to switch between UPPERCASE/lowercase,
Insert space with the "F2",
Select desired digit by repeated pressing of "F3",
Press "SET/SEND" to confirm and save changes, the display will
automatically refresh,
Press "ENT/ESC" to skip (changes will not be saved).
Press "V" to move down in the menu,
Press "ꓥ" to move up in the menu,
The ">" arrow indicates the selected parameter,
Press the "ENT/ESC" key to enter to selected parameter menu. Flashing
rectangle on the display indicates ongoing information transfer between
the DIN and RC modules – wait for the communication to finish in order to
change the parameter setting.
