12. The „Pumps Module" submenu allows the pump RPM settings.
Filtration
0%
3 RPM
100%
2 RPM
50%
1 RPM
00%
•
3 RPM - pump speed for heating/cooling, filter backwash, manual filtration mode ON without dosing/heating
•
2 RPM - pump speed for filtration mode AUTO or ON with dosing/heating
•
1 RPM - pump speed for the Silent mode (AUTO)
he "Silent mode" submenu allows the activation/deactivation of the Silent mode. Time interval
T
13.
of the Silent mode can be set only over the Internet or local WIFI control using the WIFI module.
Silent mode
Inactive
22:00 – 06:00
SEND - Activate
6.4.
Controlling the VA DOS / VA PRO SALT / VA DOS OXY dosing station
" "
1.
Press the
button to wake the RC module from sleeping mode,
In the default RC screen, press the "<>" button to switch to the dosing unit control screen.
2.
If there is no dosing unit correctly connected, the dosing station control menu will not be
displayed !!!
Filtration
Dosing
Temp 22°C
Light.014
Att3 000
Note:
The dosing station screen also displays the dosing unit operation statuses: "Operation OK" / or alarms "OFA alarm"
/ "OFA stop". The alarms cannot be deactivated from the RC module – they must be reset directly on the dosing station by pressing the
"ENTER/CAL" button.
3.
You may configure certain operating parameters of a connected dosing station form your RC module.
The logic of the dosing unit menu is the same as of DIN module. Press the "V" button to enter the dosing
station main configuration menu:
Setpoint PH
>Setpoint CL
Setpoint RX
AlrBand PH
AlrBand CL
>AlrBand RX
TotalFlow
ResetFlow
Active alarms
>Language
Select "Pumps module" in the main menu and confirm with „ENT/ESC",
a)
Press "SET/SEND" to activate the RPM setting mode (%),
b)
Press "V" to lower the preset RPM %
c)
Press "ꓥ" to increase the preset RPM %
d)
Press " <>" to jump to the next line
e)
Press "SET/SEND" to confirm and save changes,
f)
A "Sending..." message will appear on the screen.
g)
"Silent mode" in the main menu and confirm with "ENT/ESC",
a)
Select
Press "SET/SEND" to activate/deactivate the Silent mode
b)
[ ON]
[ ON]
"<>"
[ ON]
Att1 015
Att4 015
Press "V" button to move down in the menu,
a)
Press "ꓥ" button to move up in the menu,
b)
The ">" arrow indicates the selected parameter,
c)
Press the "ENT/ESC" key to enter the selected parameter menu.
d)
Flashing orange rectangle on the display indicates ongoing information
transfer between the DIN/RC modules and the dosing unit – wait for the
communication to finish in order to change the parameter setting.
[≤7.0]
PH=7.2
[≥0.8]
CL=0.6ppm
T=25°C
RX=610mV
Operation
OK
Attraction 1
RPM
50%
7
