Prior to use
Displaying the Screen
1
Press to turn on the monitor.
The monitor's power indicator lights up blue.
2
Turn on the PC.
The screen image appears.
When turning on the monitor and PC for the first time with the analog signal, the Auto Adjustment
function works to adjust the clock, phase, and display position automatically.
Installing the Touch Panel Driver
Attention
• The user account to be used for installing the touch panel driver must have the "Administrators" privilege.
• When reinstalling the touch panel driver to update the driver, etc., restart the PC after uninstalling the
driver and then install it.
Uninstall the other touch panel driver, if it is installed.
1
Install the touch panel driver according to the instructions included in the EIZO
2
LCD Utility Disk (CD-ROM).
In "Supported Controllers" window, select the touch panel driver shown below corresponding to the model
used.
T1501... [DMC, TSC-10 Series, Serial]
T1502... [DMC, TSC-10 Series, USB]
Use either cable of RS-232C (FD-C38-K) or USB (MD-C93) to connect the monitor
3
and the PC.
Connectors on the
PC
COM port
Connectors on the
PC
USB port
4
Restart the PC.
4
Installation
[ T1501]
RS-232C Cable FD-C38-K (supplied)
[ T1502]
USB Cable MD-C93 (supplied)
Setting/Adjustment Troubleshooting
Connectors on the
monitor
RS-232C port
Connectors on the
monitor
USB port
