Abschnitt: Messwerte - Endress+Hauser Micropilot FMR20 Modbus RS485 Kurzanleitung

Micropilot FMR20 Modbus RS485
11.2

Abschnitt: Messwerte

Adresse Name
5105 LCRS_DISTANCE_VALUE
5117 HO_QVVALUE
5104 LCRS_SIGNALQUALITY
5102 LCRS_PRIMLE-
VOUT_VALUE
5109 LCRS_ABSECHOAMPLI-
TUDE
5111 LCRS_SNAPPEDLEVEL
5115 LCRS_SNAPPEDABSOLU-
TEECHOAMPLITUDE
5113 LCRS_SNAPPEDDISTANCE
5100 HO_PVVALUE
5107 HO_TVVALUE
Endress+Hauser
Anzahl Zugriff
Regis- • Service
ter • Bediener
2 • read only
• read only
2 • read only
• read only
1 • read only
• read only
2 • read only
• read only
2 • read only
• read only
2 • read only
• read only
2 • read only
• read only
2 • read only
• read only
2 • read only
• read only
2 • read only
• read only
Bereich Daten- SI-Einheit
typ
-inf...inf float32 m
-273.14... float32 °C
inf
strong: 0 enum8 -
medium: 1
weak: 2
no signal: 3
-inf...inf float32 according
to LE_DIS-
TANCEU-
NIT_0
-inf...inf float32 dB
-inf...inf float32 m
-inf...inf float32 dB
0 ... 21,8 float32 m
-inf...inf float32 according
to LE_PVU-
NIT_0
–60 ... 60 float32 dB
Modbus Parameter Übersicht
Beschreibung
Secondary
value of mea-
surement
(Distance)
Quaternary
value of mea-
surement
(Tempera-
ture)
Signal Quality
Primary value
of measure-
ment (Level)
Tertiary value
of measure-
ment (abso-
lute echo
amplitude)
Snapped level
Snapped abso-
lute echo
amplitude
Snapped dis-
tance
Primary value
of measure-
ment (Level
linearized)
Tertiary value
of measure-
ment (relative
echo ampli-
tude)
51
