8. MAINTENANCE TO BE CARRIEd OUT EVERY 6 MONTHS
Regular inspections should be made according to national regulations and product documentation by a Entrematic Group AB
trained and qualified technician. The number of service occasions should be in accordance with national requirements and
product documentation.
Installation / Fitting
• Tighten the fitting screws of the uprights with the crosspiece
• Check the anchoring of the door to the door frame
Motor
• Check the fixing of the motor to the relevant support
• Check the limit switches functioning and the good alignment with the cams. Check the belt tension (for type K26)
• Check the brake disc wearing. If necessary replace the disc
• Check the silent block positioning and the rubber wearing
Main Shaft
• Check the good bearing supports fixing
• Lubricate the support of the bearings by suitable grease inlet
Safety devices
• Check the good safety bar functioning
• Check the good conditions of the safety bar rubber profile
• Check the adjusting and the eventual wearing of the steel cable of the electromechanical safety edge
• Check the wearing of the mobile cable
• Check the wearing of the side plastic safety edge shoes
• Check the correct operation of the safety photocells
8.1 Maintenance Plan
The table below shows the recommended interval - in months - when to replace parts during preventive maintenance.
Part
Limit switch group
Limit switch
Limit switch belt for K26
Brake disc
Silent block
Safety edge shoe
Safety edge cabling
(1) Dirty or dusty environment, operating temperature near to 0°C or over 35°C, wind pressure within 20% of maximum limit.
date Counter
0DT826 2014-06-13
Part number <10
Low Traffic
6DODGF
36
5M
48
5T533010
36
22337
36
5SB2524
60
27925
24
27796
36
Signature
- 46 -
Cycles / hour
<30
Medium Traffic
24
36
24
24
48
24
24
date Counter
Abusive
>30 Environment
(1)
High Traffic
12 12
24 24
12 12
12 12
36 36
12 12
12 12
Signature
