USE INSTRUCTIONS

GENERAL SAFETY PRECAUTIONS

This user handbook is an integral and essential part of the product and must be delivered to the users. Keep
this document and pass it on to any future users.
This automation is a "vertical-roll door"; it must be used for the specific purpose for which it was designed. Any
other use is to be considered inappropriate and so dangerous. Entrematic Group AB declines all responsibility
for damage caused by improper, incorrect or unreasonable use.

USE PRECAUTIONS

• Do not enter the door action area while the door is moving.
• In the event of a fault or malfunctioning, turn off the main switch. The operations of maintenance, adjustment
and repair must be carried out by skilled and authorised staff.
• Each automation has its own "Installation and Maintenance handbook", reporting the periodical maintenance
plan. Please take care to check all the safety devices.
BUTTONS
• Full opening: the door opens completely. The stroke can be fixed via the end stop microswitch.
• Partial opening: the door opens partially, to a point time-regulated by the RP trimmer.
• STOP: the door stops immediately.
• Closing: the door closes completely. The stroke can be fixed via the end stop microswitch.
OPTIONAL dS - MANUAL OPERATION
• To manually raise the curtain in the event of a power failure or fault, raise the curtain to the "open door"
position, as shown.
Entrematic Group AB
Lodjursgatan 10
SE-261 44, Landskrona
Sweden
www.ditecentrematic.com
K22
Close
Open
- 45 -
K26
D o n o t l e a v e t h e m a n u a l
operation rod hanging on the ring
during normal door operating.
Use the special wall-mounted
fastening clip
Close
Open
Installer:
EN
0DT826 2014-06-13
