entrematic Ditec Smart Plus Handbuch Die Montage, Wartung, Bedienung Seite 35

48E
Id Value
F1 - F2 - F3 8A - 500V
F4 3.15A - 230V
F5 2.5A - 500V
AdjUSTMENT LIMIT SWITCH
1. Activate the door by pressing the appropriate buttons, and check it moves
in the correct direction and If necessary, reverse the movement direction
by modifying the phase sequence, adjusting the line wires upstream of
the main switch.
2. Carry the curtain in the closed position.
3. By means of a screwdriver, turn the "C" cam until the relative micro-
switch is triggered.
4. Carry out the same procedure for the opening limit switch: bring the
curtain to the open door position, and adjust cam "A".
5. Activate the automation to check the calibration and, if necessary, make
a further adjustment.
ON
1
3
9
4
LDV
LDR
20
RP TC
- LK +
11 12 17 IN
1 7 14 12 1 1 0 0 0 1 1 2 3 4 6 8 9 20 41
FUSES
dimension
10.3 x 38
5 x 20
5 x 30
EL07L
0000000000000
www.ditec.it
COM
SO EO
ON
ON
1 2 3 4 5 6
SA POWER
NIO
Circuit
Three phase line
Transformer
Dynamic brake + Brake
- 35 -
F4
U W V
Y
Z
X
L3 L2 L1
F5
F1 F2
C
0DT826 2014-06-13
EN
F3
A
