6. Troubleshooting

Despite the integrated safety systems, a problem may occur when
operating a ROXXY PROcontrol brushless controller. The following
table lists key problems, their causes and what can be done to rem-
edy them. Please check everything carefully; often the cause of a
problem is due to incorrect operation.
Problem Cause
The motor does not The ROXXY
start up, there is PROcontrol brush-
no acoustic signal less controller
when plugging in has not yet been
the battery, but the programmed to the
servos are working. throttle joystick.
Poor or no con-
nection to the drive
battery
Battery not charged
or defective
The motor does not
Poor solder connec-
start up, there is no
tions (cold solder
signal to indicate
joints)
the number of cells
Connection cable
when the battery
on the receiver con-
is plugged in and
nected incorrectly
the servos are not
(polarity has been
working either.
reversed)
Reverse polarity of
the battery
Brushless controller
defective
Two cables between
the controller and
The motor runs the the motor have
wrong way. been connected
with the wrong
polarity
Servo signal of the
throttle function has
been lost
The motor stops
unexpectedly when
flying.
Battery has
reached the set
undervoltage limit
Poor cable connec-
tions
ROXXY PROcontrol Series – Operating Instructions,
# 1-02103, 1-02104, 1-02105, 1-02106, 1-02107, 1-02108, 1-02109
Remedy
Calibrate the throttle
joystick, program
the throttle joystick
range (stop and full
throttle position).
Check the connec-
tion to the
battery precisely.
Install a new fully
charged battery.
Solder all the con-
nections again.
Check the connec-
tion, correct the
polarity reversal.
Check the polarity
of the battery.
Install a new con-
troller.
Swap two of the
cables between the
controller and the
motor or change the
running direction of
the motor by alter-
ing the
programming.
Check your radio
control set, the posi-
tion of the controller
to the receiver and
its wiring. Use a
ferrite core in the
controller connec-
tion to remedy the
problem.
Land immediately
and install a fully
charged battery.
Check the cable
connections pre-
cisely.
12
Problem Cause
External faults at
the radio control
set
Insufficient supply
Motor starts up
of cooling air
unusually and
overheats.
Excessive power
is applied to the
servos, BEC over-
loaded
Motor and / or pro-
peller are too big
GUARANTEE / LIABILITY EXCLUSION
Our products are covered by the currently valid statutory guarantee
regulations. If you wish to make a claim under guarantee, please
contact the model shop where you originally purchased the unit.
The guarantee does not cover faults caused by:
- Incorrect handling, incorrect connections, reversed polarity
- The use of accessories other than original MULTIPLEX items
- Modifications or repairs not carried out by MULTIPLEX or by an
authorised MULTIPLEX Service Centre
- Accidental or deliberate damage
- Normal wear and tear
- Use of the unit outside the stated Specification
MULTIPLEX Modellsport GmbH & Co.KG accepts no liability for loss,
damage or costs which are caused by the incorrect or incompetent
use of the product, or are con-nected with such use in any way.

CE CONFORMITY DECLARATION

This device has been assessed in accordance with
the relevant harmonised European directives. You are
therefore the owner of a product whose design fulfils
the protective aims of the European Community relating
to the safe operation of equipment. You are entitled to see the
conformity declaration.
Please ask MULTIPLEX Modellsport GmbH & Co.KG for a copy.

DISPOSAL NOTES

EElectrical equipment marked with the cancelled waste
bin symbol must not be discarded in the standard
household waste; instead it must be taken to a suitable
specialist disposal or recycling system.
In the countries of the EU (European Union), electrical
equipment must not be discarded via the normal domestic refuse
system (WEEE - Waste of Electrical and Electronic Equipment,
Directive 2002/96/EG). You can take un-wanted equipment to your
nearest local authority waste collection point or recycling centre,
where the staff will dispose of it correctly and at no cost to yourself.
By returning your unwanted equipment you can make an important
contribution to the protection of our shared environment!
Remedy
Check correct
functioning of the
set on the ground,
if the error also
occurs, start the
model at a different
location.
Place the control-
ler in a position
where it is cooled
properly.
The maximum
power of the BEC
controller must not
be exceeded by the
servos.
Adapt the motor
and / or the propel-
ler to the ROXXY
controller.
