Permitted wire cross-sections.
Rigid wire [mm
0.14 – 2.50
7

Allocation of button inputs

The 12 button inputs of the HMW-IO-12-Sw7-DR can
be assigned to actuator channels of other(!) actuators
that have channel buttons on the device without the
Homematic center.
Since this device has no programming button
for the output channels, the output channels
can only be assigned via the Homematic Cen-
ter. The device is completely unprogrammed in
delivery status.
7.1 Teaching button inputs to
actuator channels
Please read this section completely before star-
ting with any configuring!
34
2
]
Flexible wire with end
2
sleeve [mm
0.14 – 1.5
]
