Assignment of inputs

3.7 Digital input I10
3.8 Analogue input I4
4.1 Relay output 6
4.2 Digital output 7
4.3 Digital input I11
4.4 Analogue input I5
4.5 Shared connection (common) relay output
4,5,6
4.6 Digital output 8
4.7 Digital input I12
4.8 Analogue input I6
Permitted wire cross-section:
Rigid wire
[mm ]
2
0,14 – 2,50
7 Assignment of inputs
The digital and analogue inputs can be detected with
the central control unit, where they can be used in
programs (e.g. user-defined actions can be triggered
based on the voltage measured).
36
Flexible wire withend sleeve
[mm ]
2
0,14 – 1,5
