Make sure that the specified wiring and wire
cross-sections are used when connecting to
device terminals. Observe the installation
instructions for installations in distribution
systems.
3

Function

• 12 button inputs.
• Button connections can be configured as desired
and optional actuator channels can be assigned
(from other modules as well).
• 7 relay outputs.
• 3680 VA (230 V/16 A) Total switching capacity of
all relay outputs together.
• Low wiring requirements because of common
power source.
• Electrical isolation of inputs and outputs.
• Extensive configuration capabilities through the
Homematic Centers.
• Non-volatile memory for configuration data.
• Installation on a standard DIN rail within divisi-
ons.
• Electrically isolated power and bus segments.
