The button inputs are not assigned to any
actuator channels in factory status (not the
actuator channels of the device on which they
are located either).
Assignment of button inputs to actuator channels
• Press the programming button of the actuator
(channel) to be assigned on the module until
the channel LED flashes slowly (after approx. 3
seconds). The module is now in teach mode.
• Now, actuate a button on the button input (on the
same module or any other module on the bus)
that you want to assign to the actuator (channel).
• The actuator (channel) is now assigned with this
switch input and the channel LED goes dark on
the actuator.
• Test the assignment by pressing the respective
button. The actuator (channel) should react ac-
cording to the configuration of the button input.
• If you want to assign another button input to the
actuator (channel), repeat this procedure.
