Tip 6 Improve grounding
1. Drive the earth rods into damp soil at least 1 m deep and 10 m away from the building.
2. If necessary, add more rods at a distance of at least 3 m between them and connect them together.
Earth rods must be non-rusting, which means they are either stainless steel or galvanised.
Tip 7 Typical layout of an electric fence system
3
2
1. Energiser
It supplies power to the fence system. The choice of a unit depends on the total fence length, animal
species to be fenced in or out and available power supply options. There are 9 V battery energisers, 12V
rechargeable battery energisers and mains energisers.
2. High voltage cable
This cable is multi-purpose. It is used, among other things, to connect the energiser to the grounding rod
or connecting several rods together. In addition, high-voltage cables are used to pass electricity close to the
ground or underground.
Tip: Only 1-core (high-voltage suitable) cables may be used and never commercially available 3-core
household cables (NYM cables). To prevent damage from stones, rodents, etc, you can pass the
cable through a garden hose or similar.
38
INSTRUCTION MANUAL POWER XXL – B 9000 – B 9000-S – B 12000 – B 12000-S
4
1
5
2
6
