1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D­89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by the
product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu­
lations and VDE regulations 0100, DIN 57113 /
VDE0113.
We recommend:
Read through the complete text in the operating in­
structions before installing and commissioning the
device. The operating instructions are intended to
help the user to become familiar with the machine and
take advantage of its application possibilities in ac­
cordance with the recommendations. The operating
instructions contain important information on how to
operate the machine safely, professionally and eco­
nomically, how to avoid danger, costly repairs, reduce
downtimes and how to increase reliability and service
life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regula­
tions that apply for the operation of the machine in
your country. Keep the operating instructions package
with the machine at all times and store it in a plastic
cover to protect it from dirt and moisture. Read the
instruction manual each time before operating the ma­
chine and carefully follow its information. The machine
can only be operated by persons who were instructed
concerning the operation of the machine and who are
informed about the associated dangers. The minimum
age requirement must be complied with.
In addition to the safety notes contained in the present
operating instructions and the special regulations of
your country, the generally recognized technical rules
for the operation of woodworking machines must be
observed.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
We accept no liability for damage or accidents which
arise due to non­observance of these instructions and
the safety information.
2. Layout (Fig. 1)
1. Back handle
2. Trigger
3. Safety switch
4. Flap
5. Quick acting lock
6. Telescopic tube
7. Cutting blade
8. Protective cover for cutting blade
9. Motor
10. Push button for angle adjustment of cutting blade
11. Quick acting lock
12. Mains cable
13. Cable hook

3. Scope of delivery

• Open the packaging and take out the equipment
with care.
• Remove the packaging material and any packaging
and/or transportation braces (if available).
• Check to see if all items are present.
• Inspect the equipment and accessories for trans­
port damage. In case of complaints the supplier is
to be informed immediately. Complaints received
at a later date will not be acknow ledged.
• If possible, keep the packaging until the end of the
guarantee period.
• Read the operating instructions to make yourself
familiar with the device prior to using it.
• After that, please dispose of it in an environmen­
tally friendly way.
• Only use original parts for accessories as well as
for wearing and spare parts. Spare parts are avail­
able from your specialized dealer.
• Specify our part numbers as well as the type and
year of construction of the device in your orders.
m Important!
The equipment and packaging material are not toys.
Do not let children play with plastic bags, foils or
small parts. There is a danger of swallowing or suff
ocating!
Fig. 1
• Motor with cutting head
• Operating handle
• Protector blade
• Shoulder strap
• Allen key
