7.3 Opening the cover with a window, removing the display module
and display module carrier
1 →
2.
1.
3 mm
7.4 Replacing the electronics module
If a T-DAT is present, do not forget when replacing the electronics to remove the T-DAT
(item 1 in Fig. 1 below), store it in a safe place and plug it back in after reassembly.
Device parameters could be lost otherwise.
Proceed as described in Section 7.1 →  7 or Section 7.2 →  7 or Section 7.3 →  8 and as
illustrated in the diagrams below.
1 →
1.
2.
4
2.
1.
T20
8
2
3. 3.
1.
3.
T20
2 →
2.
T10
2.
4.
3 →
1.
T8
1.
2.
